Sharp LC-40LE530E Service Manual

87
LC-32LE530
LC-40LE530
MARK * : SPARE
DELIVERY SECTION (G: EPC SHARP GmbH)
REF No. PARTS DESCRIPTION *
PRICE
CODE
30070333 TFT 32FHD100HZ ELED LG LC320EUD-SDA2 PL G --
30070542 TFT 40FHD100HZ ELED SAM LTA400HF24 G --
20567095 CHS.ASSY.17MB61-B331212H191C12231222M (MAIN LC32LE530E) G --
20565400
MD.ASSY.17LD98-7-26880(25/35(SHARP)RED/GR (I/R & LED BOARD
LC32LE530)
G--
! 20555220 MD.ASY. 17PW07-32"(MB61&70_SHARP) (POWER BOARD LC32LE530) G --
20468754 MD.ASY. 17TK124CY-XX850 (V5.0 SW ) G --
20567456 CHS.ASSY.17MB61-B331212H191C122312146 (MAIN LC40LE530E) G --
20565404
MD.ASY.17LD98-7-37-42880(25/35(SH)RED/GR ( I/R & LED BOARD
Whit cable LC40LE530E)
G--
! 20554268 MD.ASSY.17PW07-42" (MB61&70_SHARP) (POWER BOARD LC40LE530) G --
U1 30069750 IC MSD9WB7GX-LF-2-T1 DIVX TFBGA505 ROHS G --
U1 40042688 SUPER THIN POWDER (25*25*2)Rohs G --
U10 30067466 IC FLASH SPI 8Mb W25Q80BV SO8 ROHS G --
U11 30036983 IC EEPROM 24LC02 2Kbx8 SO8 RoHS G --
U115 30032028 IC MUX/DEMUX 74HCT4053 SO16 RoHS G --
U119 30067295 IC LDO APL5910 1.2V/1A SOP-8P ROHS G --
U120 30069973 IC STMPS2161 MB61 SOT23-5L ROHS G --
U121 30069973 IC STMPS2161 MB61 SOT23-5L ROHS G --
U124 30054012 IC 74LCX245 (TSSOP-20) ROHS G --
U125 30054012 IC 74LCX245 (TSSOP-20) ROHS G --
U128 30054012 IC 74LCX245 (TSSOP-20) ROHS G --
U129 30053941 IC 74LCX244 (TSSOP-20) ROHS G --
U13 30066009 IC FLASH SPI 16Mb SO8-DIGITAL-ROHS G --
U14 30060985 IC STEP DOWN MP2112 1A QFN6 RoHS G --
U15 30064353 IC HEADPHONE TDA1308T MB35 SO8 RoHS G --
U18 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U19 30060985 IC STEP DOWN MP2112 1A QFN6 RoHS G --
U21 30066925 IC STEP DOWN MP1484 ADJ/3A SO8 RoHS G --
U24 30066412 IC AAMP MAX9736A 2x15W BTL TQFN32 ROHS G --
INTEGRATED CIRCUITS
32LE530/40LE530/ LCD PANEL
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY
PRINTED WIRING BOARDS
LC32LE530E- MB61
MAIN UNIT
REF No. PARTS DESCRIPTION *
PRICE
CODE
U25 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U26 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U27 30066921 IC DVB-T/VIF DEMOD MSB1210 LQFP48 ROHS G --
U3 30057644 IC DOPAMP TL062 SO8 RoHS G --
U31 30067278 IC FRC MST7321P QFP216 ROHS G --
U31 40043122 SUPER THIN POWDER (20*20*2)Rohs G --
U34 30060852 IC ANALOG 2:1SWITCH FSA3157 SC70 ROHS G --
U39 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U4 30067982 IC DDR2 64Mx16 NT5TU64M16GG-AC BGA84ROH G --
U5 30067982 IC DDR2 64Mx16 NT5TU64M16GG-AC BGA84ROH G --
U6 30069934 IC NAND 512Mb K9F1208U0C TSOP48 RoHS G --
U7 30062776 DIODE ESD AZ1045-04S SOT23-6 ROHS G --
U8 30067868 IC QAM DEMOD. MSB1224 QFP48 ROHS G --
U9 30068774 IC DDR2 32MX16 W9751G6JB-18ROHS G --
Q1 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q10 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q11 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q116 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q119 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q12 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q13 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q14 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q146 30001458 TR BC858B SMD G --
Q148 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q150 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q152 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q155 30001458 TR BC858B SMD G --
Q156 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q157 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q158 30069749 TR NMOS BSH105 1.05A/30V SOT23 ROHS G --
Q159 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q160 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q161 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q163 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q17 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q19 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q2 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q20 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q25 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q27 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q28 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q3 30001458 TR BC858B SMD G --
Q30 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q31 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q32 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q33 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q35 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q36 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q39 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q41 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q42 30001458 TR BC858B SMD G --
Q43 30007800 TR NBJT BF799 0.35A/30V RF SOT23 RoHS G --
Q44 30001458 TR BC858B SMD G --
Q45 30001458 TR BC858B SMD G --
Q48 30001458 TR BC858B SMD G --
TRANSISTORS
PARTS LISTING
REPLACEMENT PARTS
Replacement parts which have special safety characteristics are identifi ed in this
manual.
Electrical components having such features are identifi ed by in the Replacement
Parts Listing.
The use of a substitute replacement part which does not have the same safety char-
acteristics as the factory recommended is not permitted.
Replacement parts not shown in this service manual may create shock fi re, or other
hazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the
following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO.
4. DESCRIPTION 5. CODE 6. QUANTITY
!
