Sharp LC-40LE530E Service Manual

89
LC-32LE530
LC-40LE530
REF No. PARTS DESCRIPTION *
PRICE
CODE
F729 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F73 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F730 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F734 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F737 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F738 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F740 30024778 FERRIT SMD 60R/100MHz 0.1R M 0.5A 603Ro G --
F741 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F742 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F743 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F747 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F748 30063052 FERRIT SMD 1K/100MHz 0.09R M 0.2A 0402Ro G --
F761 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F762 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F763 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F764 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F765 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F768 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F769 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F770 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F771 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F80 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F85 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F86 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F87 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F88 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F90 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F91 30020394 FERRIT SMD 330/100MHz 0.1R M 1.5A 805Ro G --
F95 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F96 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F97 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F98 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
F99 30060822 FERRIT SMD 90R/100MHz 2R5 M 0.1A 2x504Ro G --
L1 30061408 COIL SMD 4.7uH 2.4A M 54R 7x7(SHL)Ro G --
L13 30061408 COIL SMD 4.7uH 2.4A M 54R 7x7(SHL)Ro G --
L14 30066938 COIL SMD 22uH 3.6A M 0.73R 10x10x4"SHLRo G --
L15 30066938 COIL SMD 22uH 3.6A M 0.73R 10x10x4"SHLRo G --
L16 30066938 COIL SMD 22uH 3.6A M 0.73R 10x10x4"SHLRo G --
L17 30066938 COIL SMD 22uH 3.6A M 0.73R 10x10x4"SHLRo G --
L18 30068281 COIL SMD 330nH 0.15A J 2R8 603 Ro G --
L19 30068281 COIL SMD 330nH 0.15A J 2R8 603 Ro G --
L20 30068280 COIL SMD 150nH 0.15A J 2R8 402 Ro G --
L3 30049016 COIL SMD 470nH 0.25A M 0R65 805 Ro G --
L5 30016659 COIL SMD 1uH 50mA K 0R4 805 Ro G --
L9 30061048 COIL SMD 15uH 4.5A M 27R 12x12(SHL)Ro G --
TU1 30069671 TUNER DIG. HALF-NIM DTOS403LH122E RoHS G --
C10 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C100 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C101 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C102 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C103 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C104 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C105 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
TUNER
CAPACITORS
REF No. PARTS DESCRIPTION *
PRICE
CODE
C106 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C1063 30051792 CAP SMD 470NF 16V M Y5V (0402) ROHS G --
C1067 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1068 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1069 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C107 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C1075 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C1076 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C1077 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1078 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1079 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C108 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C1080 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C1081 30059259 CAP SMD 2.2UF 25V K X7R (0805) ROHS G --
C1082 30063686 CAP ELCH 100UF 16V M 105C 6.3x5.4 ROHS G --
C1084 30024769 CAP ELCH 47UF 16V M 52mA 5x5.4 ROHS G --
C1085 30024769 CAP ELCH 47UF 16V M 52mA 5x5.4 ROHS G --
C1086 30024769 CAP ELCH 47UF 16V M 52mA 5x5.4 ROHS G --
C1087 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1088 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C109 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C1095 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C11 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C110 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C1103 30022238 CAP SMD 33PF 50V J COG (0402) ROHS G --
C1104 30022238 CAP SMD 33PF 50V J COG (0402) ROHS G --
C1105 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1107 30068276 CAP SMD 30PF 50V G COG (0402) RoHS G --
C1108 30068276 CAP SMD 30PF 50V G COG (0402) RoHS G --
C1109 30061154 CAP SMD 82PF 50V J C0G (0402) MXM ROHS G --
C111 30022250 CAP SMD 330PF 50V K X7R (0402) RoHS G --
C1110 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C1112 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C1113 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C1117 30067972 CAP ELCH 100UF 35V M105C120mA6.3x7.7RoHS G --
C1118 30067972 CAP ELCH 100UF 35V M105C120mA6.3x7.7RoHS G --
C1119 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C112 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C1120 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1122 30022244 CAP SMD 100PF 50V J COG (0402) ROHS G --
C1125 30050025 CAP ELCH 220UF 6.3V M 86mA 6.3x5.4 ROHS G --
C1126 30050025 CAP ELCH 220UF 6.3V M 86mA 6.3x5.4 ROHS G --
C1127 30050025 CAP ELCH 220UF 6.3V M 86mA 6.3x5.4 ROHS G --
C1128 30050025 CAP ELCH 220UF 6.3V M 86mA 6.3x5.4 ROHS G --
C1129 30001734 RES SMD 1/10W 0R 0805 ROHS G --
C113 30069618 CAP SMD 100NF 50V K X5R (0402) RoHS G --
C1132 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C1135 30050025 CAP ELCH 220UF 6.3V M 86mA 6.3x5.4 ROHS G --
C114 30069618 CAP SMD 100NF 50V K X5R (0402) RoHS G --
C1144 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1145 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1146 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1147 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1148 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1149 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C115 30069618 CAP SMD 100NF 50V K X5R (0402) RoHS G --
