Sharp LC-40LE530E Service Manual

91
LC-32LE530
LC-40LE530
REF No. PARTS DESCRIPTION *
PRICE
CODE
C260 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C261 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C262 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C263 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C264 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C266 30062607 CAP POS 220UF 4V M ESR=15mR 2.7A ROHS G --
C267 30047294 CAP SMD 4.7UF 10V K X5R (0805) ROHS G --
C268 30010555 CAP SMD 1UF 16V K X7R (0805) ROHS G --
C269 30010555 CAP SMD 1UF 16V K X7R (0805) ROHS G --
C27 30059259 CAP SMD 2.2UF 25V K X7R (0805) ROHS G --
C271 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C272 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C273 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C274 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C275 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C276 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C277 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C28 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C280 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C281 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C282 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C283 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C287 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C289 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C290 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C291 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C292 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C293 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C294 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C295 30062607 CAP POS 220UF 4V M ESR=15mR 2.7A ROHS G --
C296 30050025 CAP ELCH 220UF 6.3V M 86mA 6.3x5.4 ROHS G --
C297 30062607 CAP POS 220UF 4V M ESR=15mR 2.7A ROHS G --
C299 30062607 CAP POS 220UF 4V M ESR=15mR 2.7A ROHS G --
C3 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C30 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C300 30062607 CAP POS 220UF 4V M ESR=15mR 2.7A ROHS G --
C301 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C302 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C303 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C305 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C306 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C307 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C308 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C309 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C310 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C312 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C313 30010560 CAP SMD 220NF 25V K X7R (0805) ROHS G --
C32 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C320 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C322 30015459 CAP SMD 470NF 25V K X7R (0805) RoHS G --
C325 30022235 CAP SMD 18PF 50V J COG (402) ROHS G --
C326 30022235 CAP SMD 18PF 50V J COG (402) ROHS G --
C327 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C328 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C329 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C33 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
REF No. PARTS DESCRIPTION *
PRICE
CODE
C330 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C331 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C332 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C335 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C336 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C337 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C338 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C339 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C34 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C341 30022200 CAP SMD 1NF 50V J X7R (0402) ROHS G --
C342 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C343 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C344 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C345 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C346 30022200 CAP SMD 1NF 50V J X7R (0402) ROHS G --
C347 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C348 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C349 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C35 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C350 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C351 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C352 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C353 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C354 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C355 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C356 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C357 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C358 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C359 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C360 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C361 30022200 CAP SMD 1NF 50V J X7R (0402) ROHS G --
C362 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C363 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C364 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C365 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C367 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C368 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C37 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C370 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C371 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C372 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C373 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C374 30022200 CAP SMD 1NF 50V J X7R (0402) ROHS G --
C375 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C378 30001734 RES SMD 1/10W 0R 0805 ROHS G --
C38 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C381 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C382 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C383 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C388 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C389 30022200 CAP SMD 1NF 50V J X7R (0402) ROHS G --
C39 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C392 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C393 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C394 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C395 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
