Preparation
13
CAUTION
• Toprotectallequipment,alwaysturnofftheTVbeforeconnectingtoaVCR, game console, camcorder,DVDplayer,Digital
TVSetTopBox(STB),PCorotherexternalequipment.
• Refertotherelevantoperationmanual(DigitalTVSetTopBox(STB),VCR,DVDplayer,etc.)carefullybeforemaking
connections.
Connecting external devices
YoucanconnectmanytypesofexternalequipmenttoyourTV,likeaVCR,DigitalTVSetTopBox(STB),game
console,camcorder,DVDplayerandPC.Toviewexternalsourceimages,selecttheinputsourcefrom
on the
remote control unit or
INPUT
ontheTV.
w
When using component cable (commercially available)
w
When using AV cable (commercially available)
w
When using HDMI cable (commercially available)
Digital TV STB/VCR/Game
console/Camcorder/DVD
Player/PC
Digital TV STB/VCR/Game
console/Camcorder/DVD
Player
Digital TV STB/VCR/
Game console/
Camcorder/DVD
Player
NOTE
• WhenusingaTVset-topboxtowatchTVprograms,usetheset-topboxremotecontroltoswitchchannels.
NOTE
• Inserttheterminalsbycolour.
NOTE
• Inserttheterminalsbycolour.
R– AUDIO – L
YP
B
PR
Y(Green)
Audio-R(Red)Audio-L(White)
P
R
(Red)
P
B
(Blue)
Audio-R(Red)
Video(Yellow)
Audio-L(White)
