Sharp LC-40SH340K Service Manual

101
LC-40SH340E
LC-40SH340K
20499393 FRONT 40883W/TB(B.C.BL/P-V(SHARP/S)(VO) CABINET G 
20565214 BC.40883 MB60 WO/KL&PB&CH W/SNP(I)V0(SHARP) BACK OVER G 
40042936 LENS.COSM.LCD40883(AKR)-SILV-SILK PRINT G 
40043120 LED IR LENS TFT XX856 (% MILKY) VER2. (I/R lens) G 
30069264 CNAS 8P-6/1150 CY W/DC+FER UL1571#28RoHS G 
45010308 FR_40_MB60_PW82 ( Metal frame ) G 
20505572 ROC.SW.26"( MB38_SHARP) Rocker Switch cable G 
20565284 FOOT ASSY 40942(GLOSSY-BLACK_SHARP(PKG) (Stand Foot) G 
45010587 DETACHABLE SHARP ST.BLACK LCD40 LED PKG(Screws and Foot Support) G 
20565245 SPK.AS. 40" (MB60 6/P(R/L)JIE(35X135(BL)_SHARP SPEAKERS G 
40046893 BRACKET IO MB45 ROCKER M2 VER21(IABVO) Side Bracket G 
30069955 CNAS 28P/210 SIS W/DC UL1061#24 SHARP RHS G 
30066220 CNAS51P-50/45010BFHD 40" UL20276#30 LVDS G 
30072030 CNAS 12P+14P/300 SISW/DCINV HM07UL1007#24 G 
! 30054983 PWR CORD SAFE EU 1800-380MM W/F+GR+H ROH (LC40SH340E) G 
! 30055588 PWR CORD SAFE UK 1800-380MM W/F+GR+H ROH (LC40SH340K) G 
20562101 R/C 1910 SHARP¬1910 (GRAYS/S) REMOTE CONTROLLER G 
20563289 SHARP LC-40SH340E (Owner Manual & Accesories ( Batteries, cables ) G 
20561066 SHARP LC-40SH340K (Owner Manual & Accesories ) (Batteries, cables) G 
20565246 SNOW BOX ASSY (T/B)40883 CCFL G 
50186865 CARTON BOX SHARP LC-40SH340E G 
50185681 CARTON BOX SHARP LC-40SH340K G 
CABINET AND MECHANICAL
PARTS LISTING
ACCESSORIES PARTS LISTING
REF No. PARTS DESCRIPTION *
REF No. PARTS DESCRIPTION *
PRICE
CODE
PRICE
CODE
PACKING PARTS LISTING
REF No. PARTS DESCRIPTION *
PRICE
CODE

Sharp LC-40SH340K Specifications

General

Teletext function	Yes
DVI port	No
HDMI version	1.3
SCART ports quantity	1
Product color	Black
Mercury content	60 mg
Panel mounting interface	400 x 400 mm
Display diagonal	40 \
Display technology	LCD
Display diagonal (metric)	102 cm
Annual energy consumption	177 kWh
Audio decoders	Dolby Digital, Dolby Virtual Speaker
RMS rated power	12 W
Power consumption (standby)	0.5 W
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-T

Weight and Dimensions

Depth (with stand)	323 mm
Width (with stand)	970 mm
Height (with stand)	657 mm
Weight (with stand)	18300 g
Depth (without stand)	91 mm
Height (without stand)	613 mm
