91
LC-40SH340E
LC-40SH340K
R
K * : SPARE
DELIVERY SECTION (G: EPC SHARP GmbH)
REF No. PARTS
DESCRIPTION
PRICE
CODE
30069440 TFT LCD 40" W SAM FHD LTA400HM07 KR G --
20565583 CHS.ASSY.17MB60-C4L1211H19232221142 (Main Board LC-40SH340E) G --
20565605 CHS.ASSY.17MB60-C4L1211H12222221142 (Main Board LC-40SH340K) G --
20579493 MD.ASY.17LD98-7-40883 (MB60(SHARP)) I/R & LED BOARD (with cable) G --
20467110 MD.ASY.17TK129CY-2-26-42855/6/7(V5.0 SW) (Touch Board ) G --
20566893 MD. ASY. 17PW82 37-42" ROC_SHA (Power Board ) G --
U145 30062776 DIODE ESD AZ1045-04S SOT23-6 ROHS G --
U149 30062763 IC STMPS2161 SOT23-5L ROHS G --
U155 30070284 IC DDR2 64Mx16 W971GG6JB-18 BGA84 ROHS G --
U157 30068667 IC MSD9WB9PX-2-T1 DIVX BGA523 RoHS G --
U157 40043122 SUPER THIN POWDER (20*20*2)Rohs G --
U158 30067466 IC FLASH SPI 8Mb W25Q80BV SO8 ROHS G --
U162 30069934 IC NAND 512Mb K9F1208U0C TSOP48 RoHS G --
U168 30068105 IC AAMP TPA3113 2x6W BTL TSSOP28 ROHS G --
U173 30070995 IC STEP DOWN RT8293A ADJ/3A SO8 RoHS G --
U175 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U176 30066926 IC STEP DOWN MP2012 ADJ/1.5A QFN6 RoHS G --
U178 30057644 IC DOPAMP TL062 SO8 RoHS G --
U180 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U181 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U3 30060852 IC ANALOG 2:1SWITCH FSA3157 SC70 ROHS G --
Q119 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q140 30029775 TR NMOS BSN20 0.17A/50V SOT23 ROHS G --
Q144 30007800 TR NBJT BF799 0.35A/30V RF SOT23 RoHS G --
Q146 30001458 TR BC858B SMD G --
Q170 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q171 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q173 30001458 TR BC858B SMD G --
INTEGRATED CIRCUITS
TRANSISTORS
40SH340 LCD PANEL
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY
LC40SH340E/K- MB60
MAIN UNIT
REF No. PARTS
DESCRIPTION
PRICE
CODE
Q174 30001458 TR BC858B SMD G --
Q178 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q180 30001458 TR BC858B SMD G --
Q181 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q185 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q186 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q188 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q189 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q190 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q191 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q192 30010733 TR NMOS 2N7002 0.1A/60V SOT23 ROHS G --
Q193 30001458 TR BC858B SMD G --
Q194 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q195 30001458 TR BC858B SMD G --
Q199 30018060 TR PMOS FDC642P -4A/-20V SSOT6 ROHS G --
Q202 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q203 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q204 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q205 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q207 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q208 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q209 30069749 TR NMOS BSH105 1.05A/30V SOT23 ROHS G --
Q210 30010733 TR NMOS 2N7002 0.1A/60V SOT23 ROHS G --
D145 30012411 DIODE SMD BA782 0.1A 35V SOD123 ROHS G --
D165 30042066 DIODE SMDSCH1N5819 1A/40V/25A SOD123ROHS G --
D169 30019996 DIODE BAV70 215mA/75V 4A SOT23 RoHS G --
D171 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D173 30062776 DIODE ESD AZ1045-04S SOT23-6 ROHS G --
D174 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D175 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D176 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D177 30053657 DIODE ARRAY ESD NUP4004M5 TSOP-5 RoHS G --
D178 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D184 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D185 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D186 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D189 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D191 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D192 30049510 FUSE SAFE SMD 3A 32V DC (1206) ROHS G --
D2 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D203 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D204 30038502 DIODE SMD ZEN B5.1V SOD123 ROHS G --
D7 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
X2 30057263 XTAL 24MHz 22pF 30ppm 25OhmHC49S SMDROHS G --
F179 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO G --
F181 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F187 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F200 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F201 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F202 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F203 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F205 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
DIODES
PACKAGED CIRCUITS
COILS AND FILTERS
REPLACEMENT PARTS





