Sharp LC-40SH340K Service Manual

60
LC-40SH340E
LC-40SH340K
21. FDC642
21.1. General Description
This P-Channel 2.5V specified MOSFET is produced using Fairchild’s advanced PowerTrench® process that
has been especially tailored to minimize on-state resistance and yet maintain low gate charge for
superior switching performance.
These devices have been designed to offer exceptional power dissipation in a very small footprint for
applications where the larger packages are impractical.
21.2. Features
x -4.5 V, ID = -4.0 A
x -2.5 V, ID = -3.2 A
x Fast switching speed
x Low gate charge (11nC typical)
x High performance trench technology for extremely low rDS(on)
x SuperSOTTM-6 package: small footprint (72% smaller than standard SO-8); low profile (1
mm thick)
x Termination is Lead-free and RoHS Compliant
21.3. Pinning
20.
20.3
20.1
20.2

Sharp LC-40SH340K Specifications

General

Teletext function	Yes
DVI port	No
HDMI version	1.3
SCART ports quantity	1
Product color	Black
Mercury content	60 mg
Panel mounting interface	400 x 400 mm
Display diagonal	40 \
Display technology	LCD
Display diagonal (metric)	102 cm
Annual energy consumption	177 kWh
Audio decoders	Dolby Digital, Dolby Virtual Speaker
RMS rated power	12 W
Power consumption (standby)	0.5 W
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-T

Weight and Dimensions

Depth (with stand)	323 mm
Width (with stand)	970 mm
Height (with stand)	657 mm
Weight (with stand)	18300 g
Depth (without stand)	91 mm
Height (without stand)	613 mm
