Sharp LC-40SH340K Service Manual

21
LC-40SH340E
LC-40SH340K
2.3.Pinning:
Pin no. Terminal Name Pin Description
1 Ant Power Active Antenna Power
2 B+ +5V, Supply Voltage (Preamplifier, DC/DC)
3 RF AGC RF AGC (internal or external mode)
4 CL I2C Serial Clock
5 DA I2C Serial Clock
6 BP +5V, Supply Voltage (RF Amp, PLL, IF Amp)
7 BT(T.P) +33V, within DC/DC circuit
8 AS I2C Address Selection of the PLL
9 IF AGC Control voltage for the IF AGC
10 IF OUT + Output 2 of the IF Amplifier
11 IF OUT - Output 1 of the IF Amplifier
12 AIF Output IF output of the Analog Broad-Band

Sharp LC-40SH340K Specifications

General

Teletext function	Yes
DVI port	No
HDMI version	1.3
SCART ports quantity	1
Product color	Black
Mercury content	60 mg
Panel mounting interface	400 x 400 mm
Display diagonal	40 \
Display technology	LCD
Display diagonal (metric)	102 cm
Annual energy consumption	177 kWh
Audio decoders	Dolby Digital, Dolby Virtual Speaker
RMS rated power	12 W
Power consumption (standby)	0.5 W
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-T

Weight and Dimensions

Depth (with stand)	323 mm
Width (with stand)	970 mm
Height (with stand)	657 mm
Weight (with stand)	18300 g
Depth (without stand)	91 mm
Height (without stand)	613 mm
