Sharp LC-40SH340K Service Manual

93
LC-40SH340E
LC-40SH340K
REF No. PARTS
DESCRIPTION

PRICE
CODE
C1190 30022196 CAP SMD 470PF 50V J X7R (0402) ROHS G --
C1195 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1196 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1197 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1198 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C1199 30067968 CAP SMD 10UF 10V M X7R (0805) ROHS G --
C120 30064117 CAP SMD 10UF 16V K X5R (0805) RoHS G --
C1200 30066876 CAP SMD 4.7UF 10V K X7R (0805) ROHS G --
C1201 30064783 CAP SMD 1UF 6.3V K X6S (0402) ROHS G --
C1202 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C1203 30050554 CAP SMD 1UF 6.3V M X5R (0402) RoHS G --
C1205 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C1206 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C1208 30067972 CAP ELCH 100UF 35V M105C120mA6.3x7.7RoHS G --
C1209 30067972 CAP ELCH 100UF 35V M105C120mA6.3x7.7RoHS G --
C1210 30061154 CAP SMD 82PF 50V J C0G (0402) MXM ROHS G --
C1212 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C1213 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C1214 30063686 CAP ELCH 100UF 16V M 105C 6.3x5.4 ROHS G --
C135 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C14 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C143 30024769 CAP ELCH 47UF 16V M 52mA 5x5.4 ROHS G --
C2 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C3 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C378 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C5 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C545 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C546 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C547 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C6 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C610 30067872 CAP SMD 10UF 10V M X5R (0805) ROHS G --
C630 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C653 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C654 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C656 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C657 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C658 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C663 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C664 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C683 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C687 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C7 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C709 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C710 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C711 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C712 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C713 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C714 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C715 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C716 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C718 30051167 CAP SMD 220NF 10V X7R K (0402) ROHS G --
C729 30022342 CAP SMD 10NF 16V J X7R (0402) ROHS G --
C782 30067595 CAP SMD 22UF 16V M X5R (1206) RoHS G --
C794 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C795 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C796 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
REF No. PARTS
DESCRIPTION

PRICE
CODE
C797 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C798 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C799 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C802 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C803 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C804 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C805 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C806 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C807 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C808 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C809 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C810 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C823 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C828 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C829 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --
C830 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C831 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C832 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C833 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C835 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C836 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C838 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C839 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C840 30022248 CAP SMD 220PF 50V J COG (0402) RoHS G --
C853 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C854 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C855 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C856 30022336 CAP SMD 3.3NF 50V J X7R (0402) ROHS G --
C857 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C858 30022338 CAP SMD 4.7NF 50V J X7R (0402) RoHS G --
C859 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C860 30022240 CAP SMD 47PF 50V J COG (0402) ROHS G --
C861 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C862 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C868 30047296 CAP SMD 22UF 6.3V M X5R (0805) ROHS G --
C881 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C882 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C883 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C884 30022351 CAP SMD 47NF 16V J X5R (0402) ROHS G --
C885 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C886 30062359 CAP SMD 47NF 16V K X7R (0402) ROHS G --
C901 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C902 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C903 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C904 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C905 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C906 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C907 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C910 30030097 CAP SMD 100NF 10V K X5R (0402) RoHS G --
C912 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C913 30044848 CAP SMD 100NF 16V K X7R (0402) ROHS G --
C942 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C943 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C944 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C945 30030099 CAP SMD 1NF 50V K X7R (0402) ROHS G --
C949 30022237 CAP SMD 27PF 50V J COG (0402) ROHS G --

Sharp LC-40SH340K Specifications

General

Teletext function	Yes
DVI port	No
HDMI version	1.3
SCART ports quantity	1
Product color	Black
Mercury content	60 mg
Panel mounting interface	400 x 400 mm
Display diagonal	40 \
Display technology	LCD
Display diagonal (metric)	102 cm
Annual energy consumption	177 kWh
Audio decoders	Dolby Digital, Dolby Virtual Speaker
RMS rated power	12 W
Power consumption (standby)	0.5 W
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-T

Weight and Dimensions

Depth (with stand)	323 mm
Width (with stand)	970 mm
Height (with stand)	657 mm
Weight (with stand)	18300 g
Depth (without stand)	91 mm
Height (without stand)	613 mm
