Sharp LC-40SH340K Service Manual

99
LC-40SH340E
LC-40SH340K
REF No. PARTS
DESCRIPTION

PRICE
CODE
R1006 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R1007 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R1010 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R1011 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R1012 30000469 RES SMD 1/10W 1K J 0805 ROHS G --
R1013 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R1014 30000464 RES SMD 1/10W 100R J 0805 ROHS G --
R1020 30001735 RES SMD 1/8W 0R 1206 ROHS G --
R1022 30006462 RES SMD 1/10W 22R J 0805 ROHS G --
R1023 30010643 RES SMD 1/10W 39R J 0805 ROHS G --
R1024 30000529 RES SMD 1/10W 1.5K J 0805 ROHS G --
R1025 30025823 RES SMD 1/10W 15K F 0805 ROHS G --
R1026 30000688 RES SMD 1/10W 390R J 0805 ROHS G --
R1027 30064582 RES SMD 1/8W 18K F 0805 ROHS G --
R1030 30012355 RES SMD 1/10W 6.8K F 0805 RoHS G --
R1031 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R1032 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R1037 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R1038 30000614 RES SMD 1/10W 2.4K J 0805 RoHS G --
R1039 30064582 RES SMD 1/8W 18K F 0805 ROHS G --
R1040 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R1044 30007791 RES SMD 1/10W 4.7K F (0805) ROHS G --
R1046 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R1047 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
R1048 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
R1049 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
R1125 30007026 RES SMD 1/10W 5.1K J 0805 ROHS G --
R1126 30000524 RES SMD 1/10W 150R J 0805 ROHS G --
R1127 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R1128 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R1129 30000494 RES SMD 1/10W 120R J 0805 ROHS G --
R1130 30000517 RES SMD 1/10W 15R J 0805 ROHS G --
R1133 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R1134 30007789 RES SMD 1/10W 27K F 0805 ROHS G --
R1136 30000606 RES SMD 1/10W 2.2M J (0805) RoHS G --
R1137 30000524 RES SMD 1/10W 150R J 0805 ROHS G --
R1138 30000524 RES SMD 1/10W 150R J 0805 ROHS G --
R1139 30000524 RES SMD 1/10W 150R J 0805 ROHS G --
 R801 30018085 CAP VAR SAFE 510V K MFCN14D511 ROHS G --
R802 30000653 RES SMD 1/10W 33R J 0805 ROHS G --
R804 30000751 RES SMD 1/10W 5.6K J 0805 ROHS G --
R809 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R810 30000653 RES SMD 1/10W 33R J 0805 ROHS G --
R811 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R812 30000609 RES SMD 1/10W 2.2R J 0805 ROHS G --
R815 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R817 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R818 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
R819 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
R820 30000597 RES SMD 1/10W 22K J 0805 ROHS G --
R822 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R823 30000517 RES SMD 1/10W 15R J 0805 ROHS G --
R824 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R826 30000563 RES SMD 1/10W 1.8K J 0805 ROHS G --
R828 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R829 30006765 RES MO 2W 0.22R J TAPED RoHS G --
REF No. PARTS
DESCRIPTION

PRICE
CODE
R830 30006765 RES MO 2W 0.22R J TAPED RoHS G --
R831 30000563 RES SMD 1/10W 1.8K J 0805 ROHS G --
R832 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R833 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R834 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R836 30064313 RES SMD 1/10W 12K F (0805) ROHS G --
R837 30000755 RES SMD 1/10W 56K J 0805 ROHS G --
R838 30000593 RES SMD 1/10W 2.2K J 0805 ROHS G --
R839 30000664 RES SMD 1/10W 3.3K J 0805 ROHS G --
R841 30000631 RES SMD 1/10W 2.7K J 0805 ROHS G --
R846 30000464 RES SMD 1/10W 100R J 0805 ROHS G --
R852 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R855 30000480 RES SMD 1/10W 100K J 0805 ROHS G --
R856 30000721 RES SMD 1/10W 4.7K J 0805 ROHS G --
R857 30000503 RES SMD 1/10W 12K J 0805 ROHS G --
R858 30000721 RES SMD 1/10W 4.7K J 0805 ROHS G --
R859 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R860 30000710 RES SMD 1/10W 47R J 0805 ROHS G --
R861 30000710 RES SMD 1/10W 47R J 0805 ROHS G --
R862 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R863 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R864 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R865 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R866 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R867 30025823 RES SMD 1/10W 15K F 0805 ROHS G --
R868 30025823 RES SMD 1/10W 15K F 0805 ROHS G --
R869 30000469 RES SMD 1/10W 1K J 0805 ROHS G --
R870 30007026 RES SMD 1/10W 5.1K J 0805 ROHS G --
R872 30000664 RES SMD 1/10W 3.3K J 0805 ROHS G --
R873 30000464 RES SMD 1/10W 100R J 0805 ROHS G --
R874 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R875 30012852 RES SMD 1/10W 3.9K F 0805 ROHS G --
R876 30058193 RES SMD 1/8W 30K F 0805 ROHS G --
R877 30007789 RES SMD 1/10W 27K F 0805 ROHS G --
R879 30015227 RES SMD 1/10W 1.2K F 0805 RoHS G --
R880 30000644 RES SMD 1/10W 3K J 0805 ROHS G --
R881 30000814 RES SMD 1/10W 820R J 0805 ROHS G --
R882 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R883 30000664 RES SMD 1/10W 3.3K J 0805 ROHS G --
R884 30010641 RES SMD 1/10W 27R J 0805 ROHS G --
R887 30015227 RES SMD 1/10W 1.2K F 0805 RoHS G --
R888 30000735 RES SMD 1/10W 4.7R J 0805 ROHS G --
R889 30000735 RES SMD 1/10W 4.7R J 0805 ROHS G --
R891 30000721 RES SMD 1/10W 4.7K J 0805 ROHS G --
R892 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R893 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R912 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R929 30000494 RES SMD 1/10W 120R J 0805 ROHS G --
R931 30007789 RES SMD 1/10W 27K F 0805 ROHS G --
R932 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R933 30000503 RES SMD 1/10W 12K J 0805 ROHS G --
R940 30050066 RES SMD 1/4W 649K F 1206 ROHS G --
R946 30000567 RES SMD 1/10W 18K J 0805 ROHS G --
R947 30000782 RES SMD 1/10W 68K J (0805) ROHS G --
R948 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R949 30000668 RES SMD 1/10W 33K J 0805 ROHS G --

Sharp LC-40SH340K Specifications

General

Teletext function	Yes
DVI port	No
HDMI version	1.3
SCART ports quantity	1
Product color	Black
Mercury content	60 mg
Panel mounting interface	400 x 400 mm
Display diagonal	40 \
Display technology	LCD
Display diagonal (metric)	102 cm
Annual energy consumption	177 kWh
Audio decoders	Dolby Digital, Dolby Virtual Speaker
RMS rated power	12 W
Power consumption (standby)	0.5 W
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-T

Weight and Dimensions

Depth (with stand)	323 mm
Width (with stand)	970 mm
Height (with stand)	657 mm
Weight (with stand)	18300 g
Depth (without stand)	91 mm
Height (without stand)	613 mm
