Sharp LC-52XS1E Service Manual

LC-52XS1E/RU/LC-65XS1E/RU
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE800VJ01 CL N J IF Unit
N DUNTKE802VJ01 AY N J R/C, LED Unit
N DUNTKE803VJ01 AN N J USB Unit
N DUNTKE805VJ01 AL N J SP-T Unit
N RDENCA304WJQZ CA N J MAIN POWER Unit
N RDENCA305WJQZ CC N J SUB-1 POWER Unit
N RDENCA306WJQZ CC N J SUB-2 POWER Unit
N RDENCA307WJQZ CA N J SUB-3 POWER Unit (LC-65XS1E/RU)
[2] PRINTED WIRING BOARD ASSEMBLIES (UNIT REPLACEMENT ITEM)
N RUNTKE807WJQZ BQ N J KEY Unit
N RUNTKA485WJQZ BK N J AC INLET Unit (LC-52XS1E/RU)
N RUNTKA491WJQZ BK N J AC INLET Unit (LC-65XS1E/RU)
N RUNTZA074WJQZ AN N J DC OUTPUT Unit (LC-52XS1E/RU)
N RUNTZA073WJQZ AN N J DC OUTPUT Unit (LC-65XS1E/RU)
[3] LCD PANEL AND LED BACKLIGHT
N CLCDTA146UJ11 ** N J 52'' Full-HD LCD Panel + LED Backlight Module (LC-52XS1E/RU)
N R1LK520D3FZH0 FA N J 52'' Full-HD LCD Panel Module (LC-52XS1E/RU)
N R1LK0DD1ML002 ** N J 52'' LED Backlight Module Unit (LC-52XS1E/RU)
N CLCDTA145UJ12 ** N J 65" Full-HD LCD Panel + LED Backlight Module (LC-65XS1E/RU)
N R1LK645D3FZH0 GF N J 65" Full-HD LCD Panel Module (LC-65XS1E/RU)
N R1LK0DD1ML001 ** N J 65'' LED Backlight Module unit (LC-65XS1E/RU)
[4] DUNTKE800VJ01(IF Unit)
C5801 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5802 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5803 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C5804 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5805 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5806 VCAAPD1DJ476MY AF J Capacitor 47 20V Electrolytic
C5807 RC-KZA620WJZZY AA J Capacitor 0.1 25V Ceramic
C5808 RC-KZA709WJQZY AA J Capacitor 0.22 Ceramic
C5809 VCECZE1CN107MY AC J Capacitor 100 16V Electrolytic
C5823 VCECZE1CN227MY AC J Capacitor 220 16V Electrolytic
C5824 VCECZE1CN227MY AC J Capacitor 220 16V Electrolytic
C5843 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5844 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5845 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5846 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C5847 VCKYCZ1HB222KY AB J Capacitor 2200p 50V Ceramic
C5848 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5901 VCKYCZ1HB472KY AA J Capacitor 4700p 50V Ceramic
C5902 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5903 VCKYCZ1HB222KY AB J Capacitor 2200p 50V Ceramic
C5904 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C5905 RC-KZA383WJZZY AC J Capacitor 10 25V Ceramic
C5906 VCKYCZ1EB103KY AA J Capacitor 0.01 25V Ceramic
C5907 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C5908 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C5909 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5910 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5911 VCKYCZ1AB473KY AB J Capacitor 0.047 10V Ceramic
C5912 VCAAPD1DJ476MY AF J Capacitor 47 20V Electrolytic
C5914 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5915 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5916 VCKYCZ1HB472KY AA J Capacitor 4700p 50V Ceramic
C5917 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5918 VCKYCZ1EB103KY AA J
Capacitor 0.01 25V Ceramic
C5919 VCKYCZ1CB223KY AC J Capacitor 0.022 16V Ceramic
C5920 RC-KZA383WJZZY AC J Capacitor 10 25V Ceramic
C5921 VCCCCZ1HH331JY AA J Capacitor 330p 50V Ceramic
C5922 VCKYCZ1AB473KY AB J Capacitor 0.047 10V Ceramic
C5923 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5924 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C5925 VCKYCZ1CB223KY AC J Capacitor 0.022 16V Ceramic
C5926 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5927 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5928 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5930 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5931 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5932 VCAAPD1DJ476MY AF J Capacitor 47 20V Electrolytic
C5933 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5934 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5936 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5937 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5938 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5939 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5941 RC-KZA520WJQZY AA J Capacitor 1 10V Ceramic
C5943 RC-KZA383WJZZY AC J Capacitor 10 25V Ceramic
C5944 RC-KZA383WJZZY AC J Capacitor 10 25V Ceramic
C5945 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5946 VCKYCZ1AB104KY AB J Capacitor 0.1 10V Ceramic
C5947 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C5948 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
