Sharp LC-52XS1E - Key Unit

LC-52XS1E/RU/LC-65XS1E/RU
2 – 6
6. Removing of KEY Unit and LED Backlight Module
1. Remove the 2 lock screws and detach the KEY Unit.
2. Remove the 4 lock screws and detach the LED Backlight Module from Cabinet A Ass'y.
1
2
LED Backlight Module
KEY Unit
2
2
1
