Sharp LC-52XS1E Service Manual

LC-52XS1E/RU/LC-65XS1E/RU
4 – 2
[2] The voltage check of each substrate unit
2-1 IF board voltage check
2-2 MAIN-POWER-UNIT voltage check (RDENCA304WJQZ)
2-3 SUB-POWER-UNIT1 voltage check (RDENCA305WJQZ)
2-4 SUB-POWER-UNIT2 voltage check (RDENCA306WJQZ)
2-5 SUB-POWER-UNIT3 voltage check (RDENCA307WJQZ)
2-6 LCD_CONTROL_UNIT voltage check
2-7 LED_CONTROL_UNIT voltage check
Harness-NO REF-NO Pin-NO Voltage Description
PD P5801 6/7 5 BU5V
PE P5802 1/2 15 UR15V
6/7 15 S15V
US P7901 1 5 D5V
DC P7903 1 5 DC5V
KM P7905 1 3.3 BU3.3V
ADJ P7906 1 3.3 BU3.3V
RA P7907 1 3.3 BU3.3V
2 3.3 OPC3.3V
Harness-NO REF-NO Pin-NO Voltage Description
PD CN7101 6/7 5 BU5V
PE CN7001 1/2 15 UR15V
5/6 15 S15V
PI CN7104 1 5 UR15V
PS3 CN7103 1 5 BU5V
PS1 CN7102 1/2 5 BU5V
6/9 27 27V
7/10 20 20V
ACM CN7602 1/2 220 220VAC
Harness-NO REF-NO Pin-NO Voltage Description
P1 CN7104 1 15 UR15V
PS1 CN7102 1/2 5 BU5V
6/9 27 27V
7/10 20 20V
PS3 CN7103 1 5 BU5V
AC1 CN5602 1/2 220 220VAC
Harness-NO REF-NO Pin-NO Voltage Description
PS2 CN5004 1 5 BU5V
4 27 27V
5 20 20V
LA2 CN5001 1/2 27 27V
5/6 20 20V
AC2 CN5602 1/2 220 220VAC
Harness-NO REF-NO Pin-NO Voltage Description
P1 CN7104 1 15 UR15V
PS1 CN7102 1/2 5 BU5V
6/9 27 27V
7/10 20 20V
PS3 CN7103 1 5 BU5V
AC3 CN5601 1/2 220 220VAC
Harness-NO REF-NO Pin-NO Voltage Description
LC P4802 9/10 12 12V
Harness-NO REF-NO Pin-NO Voltage Description
P1 CN10 1 15 UR15V
LE CN12 1 3.3 BU3.3V
