CHAPTER 5. MAJOR IC INFORMATIONS
[1] MAJOR IC INFORMATIONS
No.
REF
No.
Name Part Code Description
Drawing
No.
[IF PCB]
1 IC6001 VHiS24CS02J-1Y 2K E2PROM
This IC is 2 K bit 2 wire serial E2PROM. This EEPROM chip stores EDID-data for
HDMI of a display. This data is controlled through I2C signals. It is written in exe-
cuting EDID WRITE on the monitor process adjustment and the 3 page. Please
write in at the time of IC exchange. The harness of LB connector on IF board
(P7908) is making a monitor's size distinction serve a double purpose.
Please write in after attaching the right harness. (The data of EDID changes by
harness classification.)
*harness LB
•52size QCNW-H636WJQZ 11pin – 12pin open
13pin – 14pin open
•65size QCNW-H623WJQZ 11pin – 12pin open
13pin – 14pin short
*harness KM
52size QCNW-H712WJQZ
65size QCNW-H709WJQZ
•8pin – 9pin short
•10pin – 11pin short
•12pin – 13pin open
1/20
2 IC6004 VHiSii9181A-1Q HDMI_SW
This IC is IC for HDMI SW.
It is used as an equalizer for waveform shaping of the case where the cable which
is not an enclosed HDMI cable is used, and the sake at the time of 10m cable
(schedule) use of an option.
1/20
3 IC6102 VHiSii9125+-1Q HDMI_RX
This IC is HDMI Receiver IC. A differential signal is input from IC6004, and it con-
verts it into 8 bits of RGB of CMOS for each.
2/20
4 IC6052 VHiTLVD1023-1Q
LVDS
TRANSMIT-
TER
This is LVDS (Low-Voltage Differential Signaling) transmitter IC.
It convert each 8 bits of RGB of CMOS from IC6102 into a LVDS signal.
3/20
5 IC6201 RH-iXC068WJQZQ
DECODER
& CPU
This IC is DECODER & MAIN CPU. Although the output from STB is 1080p,
when the signal of 480p and 1080i is directly connected to a display, the signal of
480p and 1080i is changed into 1080p by this IC. Moreover, OSD of a display is
generated here and added to a picture signal. Data reading processing is also
performed from a service terminal as a wall picture function here.
4/20
6 IC6301 RH-iXB800WJQZY
Clock Gen-
erator
This IC is a clock generator. From a 27MHz crystal oscillator, generation of
48MHz for SCC, 54MHz for STC, and 74.25MHz for PWM is performed.
5/20
7 IC6302 RH-iXB801WJQZY
CLOCK-
GEN
This IC is a clock generator. From a 27MHz crystal oscillator, generation of
54MHz for STC, 33MHz for CPLD, 33MHz for FPGA, and 33MHz for PCI is per-
formed.
5/20
8
IC6402
/3/4/5
RH-iXC511WJQZQ
512Mb-
DDR2-
SDRAM-
MEMORY
This is a 512Mb DDR2 SDRAM IC. This IC is IC for IrSS encoding.
It operates as a memory of IC6201 (DECODER).
6/20
9 IC6351 RH-iXC012WJQZQ
Ir_communi
cation con-
troller
This IC is IC for IrSS encoding.
It encodes by receiving the signal from the IrSS euphotic part on a RC/LED
board, and data is transmitted to IC6201 through SLOW BUS.
7/20
10 IC6608 VHiBR24L64F-1Y
64K
E2PROM
This IC is 64K bit serial E2PROM of 8K word *8K bit configuration.
As for this IC, the data of a portion with which IC6201 (DECODER) is processing
is saved.
8/20
11 IC6651 VHi29GL064N-1Q
64Mb-
FLASH
The S29GL064A is 64Mb-NOR Flash memory.
The software of IC6201 (DECODER) is stored.
9/20
12 IC6652 RH-iXC623WJQZQ
1Gb-NAND-
FLASH
This IC is 1 Gb-NAND-FLASH memory.
The data of IC6201 (DECODER) and the pre-install picture of a wall picture func-
tion are stored in this IC.
9/20
13 IC6702 RH-iXC588WJN1Q CPLD
This IC is CPLD (Complex Programmable Logic Device).
By SLOW BUS control signal, the reset signal sent to each device, the extended
I/O port of the control signal etc., and the modulated light signal are generated.
10/20
14 IC6804 VHiAK7770EQ-1Q S-DSP
This IC is Audio DSP. This IC is performing delayed audio delay processing of the
picture of IC6201(DECODER), analog 2.1ch processing, and processing of SRS
TruSurroundXT from I2S signal inputted from IC7103(FPGA).
11/20
15 IC6902 VHiADAU1592-1Y 1bit-AMP
This IC is 1-bit amplifier. A sampling frequency is 12.288MHz. It drives by
7.5W+7.5W in all of the 52 types and 65 types.
12/20
16 IC6951 VHiYDA147SZ-1Y SUB-P-AMP
This IC is a digital audio power amplifier. In this models, it used as woofer for SRS
TruSurroundXT, and it drives by 15W in 52 and 65 types.
13/20
