LC-52XS1E/RU/LC-65XS1E/RU
1 – 1
LC-52XS1E
Service Manual
CHAPTER 1. OPERATION MANUAL
[1] SPECIFICATIONS
Item
52" LCD COLOUR TV, Model: LC-
52XS1E (Display)
65" LCD COLOUR TV, Model: LC-
65XS1E (Display)
LCD panel
52" Advanced Super View & BLACK TFT LCD 65" Advanced Super View & BLACK TFT LCD
Resolution
2,073,600 pixels (1,920 1,080)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV Function TV-Standard Analogue CCIR (B/G, I, D/K, L/L’)
Digital DVB-T (2K/8K OFDM), DVB-C, S/S2
Receiving
Channel
VHF/UHF E2–E69 ch, F2–F10 ch, I21–I69 ch, IR A–IR J ch (Digital: IR A ch–E69 ch)
CATV Hyper-band, S1–S41 ch
TV-Tuning System Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Brightness 450 cd/m
2
Viewing angles H: 176°, V: 176°
Audio amplifier
7.5 W 2, 15 W (subwoofer)
Speaker
50 mm 120 mm 2, Ø 26 mm 2, Ø 77 mm 1
Terminal (Display) USB USB 2.0
DISPLAY INPUT
HDMI
DC OUTPUT DC 5V, 1.8A MAX
SPEAKER
OUTPUT
L/R, WOOFER
OSD language
Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian, Latvian,
Lithuanian, Norwegian, Polish, Portuguese, Russian, Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian
Power Requirement AC 220–240 V, 50 Hz
Power Consumption
(Method IEC62087)
LC-52XS1E 294 W (1.0 W Standby) LC-65XS1E
512 W (1.0 W Standby)
Weight 45.0 kg (Display) 62.5 kg (Display)
Operating temperature
0°Cto+40°C
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior
notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
NOTE
Refer to the inside back cover for dimensional drawings.
•
•
Backlight life 60,000 hours (when "Backlight" is set to the default position)
