LC-52XS1E/RU/LC-65XS1E/RU
1 – 6
[3] DIMENSIONS
113.0
(1528.0) / [1243.0]
(1312.0)/[1075.0]
(1429.0) / [1156.0]
(597.6) / [511.0]
(1046.0 ) / [878.0]
(933.0) / [765.0]
60.4
(804.0) / [652.0]
47.1
22.8
54.0
( ) : LC-65XS1E/RU
[ ] : LC-52XS1E/RU
: LC-52XS1E/RU/65XS1E/RU
Unit: mm
400.0
(314.0)
[ 2 00.0 ]
