Sharp LC-52XS1E Service Manual

LC-52XS1E/RU/LC-65XS1E/RU
12
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
FB7935 RBLN-0060TAZZY AB J Balun BLN-0060TA
FB7937 RBLN-A329WJQZY AA J Balun BLN-A329WJ
FB7938 RBLN-A329WJQZY AA J Balun BLN-A329WJ
FB7939 RBLN-A329WJQZY AA J Balun BLN-A329WJ
FB7940 RBLN-A328WJQZY AA J Balun BLN-A328WJ
FB7941 RBLN-A329WJQZY AA J Balun BLN-A329WJ
FB7942 RBLN-0207TAZZY AB J Balun BLN-0207TA
FL6901 RCRMCA025WJZZY AD J Ceramic Vibrator
FL7001 RFiLZA027WJQZY AD J Filter FILZA027W
IC5802 VHiLTC1154+-1Y AP N J IC LTC1154CS8#TRBF
IC5803 VHiBA33BCFP-1Y AE J IC BA33BC0FP-E2
IC5804 VHiBD4827G+-1Y AC J IC BD4827G-TR
IC5901 VHiBD9045FV-1Y AM J IC BD9045FV-E2
IC5902 VHiBD9045FV-1Y AM J IC BD9045FV-E2
IC6001 VHiS24CS02J-1Y AD J IC S-24CS02AFJ-TB-G
IC6003 VHiT7WB125A-1Y AE J IC TC7WBD125AFK(T5L,F)
IC6004 VHiSii9181A-1Q AM J IC Sil9181ACNU
IC6005 VHiPQ1LA185-1Y AD J IC PQ1LA185MSPQ
IC6051 VHiBH33FB1G-1Y AD J IC BH33FB1WG-TR
IC6052 VHiTLVD1023-1Q AS J IC THC63LVD1023
IC6101 VHiR1173S18-1Y AE J IC R1173S181B-E2-F
IC6102 VHiSii9125+-1Q AZ J IC SII9125CTU
IC6201 RH-iXC068WJQZQ BN J IC TC90411BXBG(O,SP)
IC6301 RH-iXB800WJQZY AL J IC ICS3732AG-32LFT
IC6302 RH-iXB801WJQZY AL J IC ICS3732G-33LFT
IC6303 VHiLCX04FT+-1Y AD J IC TC74LCX04FT(EL,K)
IC6351 RH-iXC012WJQZQ AQ J IC LR388B6
IC6352 VHiPQ1LA185-1Y AD J IC PQ1LA185MSPQ
IC6401 VHiBD3533F+-1Y AG J IC BD3533F-E2
IC6402 RH-iXC511WJQZQ AX J IC H5PS5162FFR-Y5C
IC6403 RH-iXC511WJQZQ AX J IC H5PS5162FFR-Y5C
IC6404 RH-iXC511WJQZQ AX J IC H5PS5162FFR-Y5C
IC6405 RH-iXC511WJQZQ AX J IC H5PS5162FFR-Y5C
IC6601 VHi7WH126FU-1Y AE J
IC TC7WH126FU(TE12L,F)
IC6602 VHiLCX157FT-1Y AD J IC TC74LCX157FT(EKJ)
IC6603 VHiPQ1X251M-1Y AD J IC PQ1X251M2ZPH
IC6604 VHiR1173S33-1Y AE J IC R1173S331B-E2-F
IC6605 VHiTVHC153T-1Y AE J IC TC74VHC153FT(EL,M)
IC6606 VHiBD00K5WP-1Y AF J IC BD00KA5WFP-E2
IC6607 VHiTC7W66U/-1Y AE J IC TC7W66FU(TE12L,F)
IC6608 VHiBR24L64F-1Y AK J IC BR24L64F-WE2
IC6609 VHi7WH126FU-1Y AE J IC TC7WH126FU(TE12L,F)
IC6651 VHi29GL064N-1Q AN J IC S29GL064N90TFI020H
IC6652 RH-iXC623WJQZQ AX N J IC HY27US081G1M-SPIB
IC6701 VHiTCLCX08FT1Y AD J IC TC74LCX08FT(EL,K)
IC6702 RH-iXC588WJN1Q AU N J IC EPM1270F256C5N
IC6703 VHiTC7SH08U-1Y AF J IC TC7SH08FU(TE85L,JF)
IC6801 VHiTC7W66U/-1Y AE J IC TC7W66FU(TE12L,F)
IC6802 VHiR1173S18-1Y AE J IC R1173S181B-E2-F
IC6803 VHiPQ1LA335-1Y AD J IC PQ1LA355MSPQ
IC6804 VHiAK7770EQ-1Q AX J IC AK7770EQ
IC6901 VHiPQ1X331M-1Y AD J IC PQ1X331M2ZPH
IC6902 VHiADAU1592-1Y AQ J IC ADAU1592ACPZ-RL
IC6951 VHiYDA147SZ-1Y AM J IC YDA147-SZE2
IC7001 VHiBD4827G+-1Y AC J IC BD4827G-TR
IC7002 RH-iXC331WJN9Q AS N J IC MONITOR MICON(for Monitor Interface Unit)
IC7003 VHi7WH126FU-1Y AE J IC TC7WH126FU(TE12L,F)
IC7004 VHiTCVHC32K-1Y AD J IC TC74VHC32FK(EL,K)
IC7005 VHiLCX125FT-1Y AD J IC TC74LCX125FT(EL,K)
IC7006 VHiBR24L04F-1Y AE J IC BR24L04F-WE2
IC7101 RH-iXC583WJN2Y AX N J IC EPCS16SI8N
IC7102 VHiR1173S25-1Y AE J IC R1173S251B-E2-F
IC7103 RH-iXC582WJQZQ BG N J IC EP3C25F256C8N
IC7104 VHiR1173S12-1Y AE J IC R1173S121B-E2-F
IC7501 VHiBH33FB1G-1Y AD J IC BH33FB1WG-TR
IC7502 VHiTLVD1023-1Q AS J IC THC63LVD1023
L5901 RCiLCA029WJZZY AD J Coil CILCA029WJ
L5902 RCiLCA031WJZZY AD J Coil CILCA031WJ
L5903 RCiLCA029WJZZY AD J Coil CILCA029WJ
L5904 RCiLCA029WJZZY AD J Coil CILCA029WJ
L6101 VPCBM4R7MR25NY AC J Coil Peaking 4.7µH
L6801 VPCBM4R7MR25NY AC J Coil Peaking 4.7µH
L6901 RCiLZA105WJZZY AG N J Coil CILZA105WJ
L6902 RCiLZA105WJZZY AG N J Coil CILZA105WJ
L6905 RCiLZA087WJZZY AE J Coil CILZA087WJ
L6906 RCiLZA087WJZZY AE J Coil CILZA087WJ
L6907 RCiLZA087WJZZY AE J Coil CILZA087WJ
L6951 RCiLZA091WJZZY AG N J Coil CILZA091WJ
L7901 RCiLFA071WJZZY AD J Coil CILFA071WJ
L7902 RCiLFA071WJZZY AD J Coil CILFA071WJ
L7903 RCiLFA071WJZZY AD J Coil CILFA071WJ
L7904 RCiLFA071WJZZY AD J Coil CILFA071WJ
L7905 RCiLFA071WJZZY AD J Coil CILFA071WJ
L7906 RCiLFA071WJZZY AD J Coil CILFA071WJ
L7907 RCiLFA071WJZZY AD J Coil CILFA071WJ
[4] DUNTKE800VJ01(IF Unit)
