LC-52XS1E/RU/LC-65XS1E/RU
3 – 2
2. Remote controller key operation in adjustment process mode.
1. key operation
Input mode is switched automatically when relevant adjustment is started so far as the necessary input signal is available.
3. Description of display
Remote controller key Main unit key Remote controller key Main unit key Function
P ( / )
P ( / )
Moving an item (line) by one (UP/DOWN)
VOL (+/-) VOL (+/-) Changing a selected item setting (+1/-1)
Cursor ( / )
— Turning a page (PREVIOUS / NEXT)
Cursor ( / )
— Changing a selected line setting (+10/-10)
OK — Executing a function/ canceling a test pattern.
CHP1-CHP6 W/B adjustment check. It is a BETA setup about the gamma value in each adjustment point. It is off
again in the same key pressing. *Other key input is invalid in the on condition. However, it shall be
effective when other Point keys (CHP1-CHP6) are pressed.
Page specification (1-10item) It jumps to the pressed page. The cursor position after it moves selects the first line
Line specification(1-6line) The cursor moves to the pressed line.
Screen display — It is considered as monitor process mode OSD all OFF.It displays it again by another key pressing.
No. Description Display specification
(1) Present page/number of total
pages
2char/2char Decimal Number mark.
(2) Page present title Max. 15 char “[“ “]”.
(3) Destination display EUROPE/RUSSIA/SWEDEN
(4) Model size 65/52
(5) Item name Max. 30 char
(6) Parameter Max. 60 char
(1) Present㵘page / number of total pages (3)Destination display
(2) Page present title (4) Model size
1/ 46 [INFO] INPUT1 AUTO EURO 65E_UNDER[0]
Process menu header
MONITOR MAIN Version 1.10 (E 2008/09/03 1)
NONITOR BOOT Version 1.01
Monitor SUB Version 1.05
FRC Version 71716531
LED A/MAIN/SUB version 0808236501/1.0.0/1.0.0
CPLD/FPGA Version a3 / 46
EQ DATA CHECKSUM ROM
LAMP ERROR 0
MONITOR SUB ERR CAUSE 00 00 00 00
NORMAL STANDBY CAUSE 0
ERROR STANDBY CAUSE 1) 0 2) 0 3) 0
0H 0M 0H 0M 0H 0M
4) 0 5) 0
0H 0M 0H 0M
(5) Item name 㩿㪍㪀㩷㪧㪸㫉㪸㫄㪼㫋㪼㫉
To Next Page
