Sharp LC-52XS1E Service Manual

LC-52XS1E/RU/LC-65XS1E/RU
3 – 10
38/46 [M BLCTL TEMP]
1 BL TEMP1 Disclosure
2 BL TEMP2 Disclosure
3 BL TDUTY Disclosure
39/46 [M EEP SET]
1 MONITOR TIME OUT ON Disclosure
2 MONITOR MAX TEMP 53 Disclosure
3 MONITOR EEP READ / WRITE WRITE Disclosure
4 MONITOR EEP ADR 0x 0 Disclosure
5 MONITOR EEP DATA 0x 0 Disclosure
40/46 [M TESTPTRN]
1 LCD TEST PATTERN OFF Pattern with built-in LCD controller display.
2 LCD AGI TEST PATTERN OFF Pattern with built-in LCD controller display.
3 LCD EVA TEST PATTERN OFF Pattern with built-in LCD controller display.
4 FRA TEST PATTERN OFF Pattern with built-in LCD controller display.
5 PSF TEST PATTERN OFF
41/46 [DCLP COMP]
1 YG_CLPWDY_COMP525P default Disclosure
2 RB_CLPWDC_COMP525P default Disclosure
3 AYCLPON_COMP525P default Disclosure
4 SLLSHR_GAIN_COMP525P 0 Disclosure
5 YG_CLPWDY_COMP1125I default Disclosure
6 RB_CLPWDC_COMP1125I default Disclosure
7 AYCLPON_COMP1125I default Disclosure
8 SLLSHR_GAIN_COMP1125I 0 Disclosure
9 YG_CLPWDY_COMP750P default Disclosure
10 RB_CLPWDC_COMP750P default Disclosure
11 AYCLPON_COMP750P default Disclosure
12 SLLSHR_GAIN_COMP750P 0 Disclosure
42/46 [DCLP DVI]
1 YG_CLPWDY_DVIA default Disclosure
2 RB_CLPWDC_DVIA default Disclosure
3 AYCLPON_DVIA default Disclosure
4 SLLSHR_GAIN_DVIA 0 Disclosure
5 FILTERMODE default Disclosure
43/46 [IRSS]
1 IrSS MODE ROM Disclosure
2 OPERATION MODE AUTO Disclosure
3 TEMP THREADSHOLD 175 Disclosure
4 NOISE THREADSHOLD 0 Disclosure
5 INSPECTION MENU MODE NOMAL Disclosure
44/46 [FR REGI]
1 KEY LOCK(1217) Enter Key input lock
2 KOUTEI AREA ALL CLEAR Adjustment value clearness in all areas in process
3 A MODE AREA CLEAR Adjustment value clearness of process A mode
4 BACKUP AREA CLEAR Adjustment value clearness in process backup area
5 B MODE AREA CLEAR Adjustment value clearness of process B mode
6 EXECUTION Clear execution
45/46 [MEM CLEAR]
1 READ/WRITE READ Read/Write
2 SLAVE ADDRESS FRA Slave address
3 REGISTER ADDRESS 0x 0 Register address
0x 0
4 WRITE DATA 0x 0 Writing data
0x 0
5 READ DATA 0x 0 Reading data
0x 0
Page Line Item Description Remarks (adjustment detail, etc.)
