Factory adjustments (cont...)
• Caution when replacing ICs in the MAIN Unit (IC8401, IC3303)
When replacing either IC8401 or IC3302, exchange MAIN units for DKEYDF733FM51, DKEYDF733FM52
Each part should not be individually exchanged.
IC8401 RH-iXD287WJQZQ Flash
IC3303 RH-iXD220WJQZQ Main CPU
NOTE: HDMI ROM Writing
After replacing IC1504, execute “HDMI EDID WRITE” on the 5/24.
Please execute it after checking MODEL NAME & INCH SIZE are correct.
The ROM data based on information of MODEL NAME & INCH SIZE.
1) Enter the process adjustment mode in AVC.
2) Use the cursor keys (▲/▼) and P keys (r/s) of R/C to select the item [HDMI EDID WRITE] on the page5/24.
3) It is completed with OK displayed.
Issued by:
CE After Sales Service
July 2011
Adjustment Process
