Sharp MX-2010U Technical Handy Guide

SHARP
TEST SIMULATION
37
The following pages contain information regarding test simulations. For a detailed description for each
test simulation, please refer to the MX-2010/2310U Service Manual.
Entry Code:
1
Scanner Self Test
1
Scanner operations test
2
Scanner sensor check
5
Scanner unit and control circuit check
2
RSPF Self Test
1
SPF ageing test.
2
SPF sensor check
3
SPF output check (motor, clutch, solenoid)
3
Finisher Operation & Test
2
Finisher sensor check
3
Finisher output check
10
Finisher adjustment
4
Desk / LCC Operation & Test
2
Desk/LCC sensor check
3
Desk/LCC output check
5
Desk/LCC clutch operation check
5
Lamp Operation & Test
1
LCD/LED test
2
Heater lamp load check
3
Copy lamp check
4
Discharge lamp check
6
System Load Operation & Test
1
Feed output check
2
Fan load check
3
Transfer operation check
6
Fuser Separation operation check
90
Scanner mirror unit lock position execute
7
Device Aging Operation & Test
1
Ageing test setting
6
Interval ageing cycle timer set up
8
Warm up time display setting
9
Printing colour select mode (colour)
12
Document reading setting (aging)
8
High Voltage Operation & Test
1
Developer bias setting and output
8
High Voltage Operation & Test
2
MHV/Grid setting and output
6
Transfer setting and output
9
Duplex Operation & Test
2
ADU sensor check
3
ADU load & output check
10
Toner Motor Operation & Test
1
Toner motor operation check
13
U1 Clear / Cancel
--
Trouble cancel (U1 trouble).
14
Clear / Cancel
--
Trouble cancel (excluding U2/PF trouble).
16
U2 Clear / Cancel
--
U2 trouble cancel
17
PF Clear / Cancel
--
PF trouble cancel
21
Maintenance Cycle Configuration
1
Maintenance cycle setting
22
Data Output & Check
1
Counter data display
2
Jam/trouble counter display
3
Jam history data display
4
Trouble code history data display
5
ROM version display
6
Data print mode
8
Document feed and output counter
display
9
Paper feed counter display
10
Machine system display
11
Fax counter display
12
RSPF jam history display
13
Process cartridge counter display
14
Toner cartridge use status

Sharp MX-2010U Specifications

General

Print Technology	Laser
Print Speed	20 ppm
Print Resolution	600 x 600 dpi
Scan Type	Color Scanner
Functions	Print, Copy, Scan, Fax
Copy Speed	20 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 kbps
Duplex Printing	Yes
Maximum Paper Size	A3
Connectivity	USB, Ethernet
Hard Drive	80 GB
Weight	73 kg
