Sharp MX-2300N User Manual

25
FOLDER AND FILE SELECTION SCREENS
To call up and use a stored file, the folder and file must be selected. The folder selection screen and file selection screen
are explained below.
FOLDER SELECTION SCREEN
Two different screens appear depending on whether or not user authentication is enabled on the machine.
When user authentication is not enabled When user authentication is enabled
(1) Folder keys
The Custom Folders that have been created using
"Document Filing Control" in the system settings are
displayed. Touch a folder key to display its file selection
screen.
If a password has been set for a Custom Folder, a
password entry screen will appear when the folder is
touched. The password must be entered.
(2) [Main Folder] key
Touch this key to switch between the Main Folder display
and the Custom Folder display. When the file selection
screen of the Main folder appears, this key is the
[Custom Folder] key.
(3) [Search] key
Touch this key to open the search screen. This lets you
search for a file using a user name, file, or folder name.
(4) [Back] key
Touch this key to return to the base screen of document
filing mode.
(5) Index tabs
All folders appear on the [All Folders] tab.
Touch a tab to display the Custom Folders whose initials
(set in "Document Filing Control" in the system settings)
match the letters on the tab.
(6) / keys
Use these to change the folder list page that is displayed.
(7) [My Folder] key
This key appears when user authentication is enabled.
Touch the key to display the file selection screen of My
Folder. Even if user authentication was performed, if My
Folder was not specified in the user registration settings,
this key will be grayed out to prevent selection.
Custom Folder
1/1
Search BackMain Folder
User 1
User 3
User 5
User 7
User 2
User 4
User 6
User 8
All Folders
ABCD EFGHI JKLMN OPQRST UVWXYZ
(5)
(2) (3) (4)(1)
(6)
My Folder Selection
1/1
Search Back
My Folder
User 1
User 3
User 5
Main Folder
User 2
User 4
User 6
All Folders
ABCD EFGHI JKLMN OPQRST UVWXYZ
(1)
(5) (6)
(2)(7) (3) (4)

Sharp MX-2300N Specifications

General

Print technology	Laser
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum copy resolution	600 x 600 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Total input capacity	1100 sheets
Maximum input capacity	5600 sheets
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Mac compatibility	Yes
Internal storage capacity	40 GB
Dimensions (WxDxH)	620 x 670 x 950 mm
Power requirements	230-240V AC, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	print, scan
Compatible operating systems	Windows NT 4.0 SP5+, Windows 2000, Windows Server 2003, Windows XP, Windows 98/Me, Mac OS 9.0 - 9.2.2, Mac OS X 10.1.5, 10.2.8, 10.3.3 - 10.3.9, 10.4
Supported network protocols (IPv4)	TCP/IP, IPX/SPX (NetWare), NetBEUI, EtherTalk (Appletalk)
Power consumption (average operating)	1840 W
Digital sender	No
Market positioning	Business
