Sharp MX-2600N User Manual

2-38
COPIER
Contents
Punch function
If an optional punch module is installed, holes can be punched in output.
Paper size that can be punched is 7-1/4" x 10-1/2" to 11" x 17" (B5R to A3). However, 12" x 18" (A3W) sized paper and
special media such as transparency film and tab paper cannot be used.
Original placement orientation (for the staple sort and punch functions)
When using the staple sort function or the punch function, the original must be placed as shown below to enable stapling
or punching in the desired position on the paper.
The hole punch function cannot be used with the saddle stitch or paper folding function together.
Staple sort Punch
Document feeder tray Document glass Document feeder tray Document glass
One staple (top)
Two staples
One staple (bottom)
[Original 1] [Punch positions]
[Examples]
[Original 2] [Punch positions]
abc
abc
abc
abc
abc
abc
abc
abc
abc
abc

Sharp MX-2600N Specifications

Power

power requirements	230 ~240V AC, 50/60 Hz
power consumption	1.84 kW
warm-up time	Less than 60 sec.

System Memory

copier memory	Standard 1, 024MB, max. 2, 048MB
printer memory	Standard 512MB, max. 1, 536MB
HDD	80GB

Paper Handling

standard paper capacity	1, 100 sheets
maximum paper capacity	5, 600 sheets
paper weight (tray)	60 g/m² to 209 g/m²

Weight and Dimensions

dimensions	620 x 695 x 950 mm
weight	Approx. 112 kg
