8-3
TROUBLESHOOTING
Contents
PAPER MISFEED ILLUSTRATIONS
If you require more information when reading the instructions in the touch panel, see the paper misfeed illustrations
below. Refer to the illustration below and then go to the appropriate illustration (1 to 14) for your situation.
(1)-(2): page 8-3, (3)-(9): page 8-4, (10)-(11): page 8-5, (12)-(14): page 8-6
(1) Original misfeed
Open the document feeder
cover and remove the misfed
originals.
Pull out the document feeder
tray and remove the misfed
paper.
Open the automatic
document feeder. Rotate the
transfer roller in the direction
of the arrow and remove the
original.
(2) Paper misfeed in the output area
Remove the misfed paper.
(1)(11) (12) (13) (2) (10)
(8)
(14) (9)
(3)
(4)
(5)
(6)
(7)
After removing the misfeed, open and close the
automatic document feeder (or the document feeding
area cover or document feeder tray) to clear the
misfeed display from the touch panel.

Table of Contents

Other manuals for Sharp MX-2600N

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sharp MX-2600N and is the answer not in the manual?

Sharp MX-2600N Specifications

Power IconPower
power requirements230 ~240V AC, 50/60 Hz
power consumption1.84 kW
warm-up timeLess than 60 sec.
System Memory IconSystem Memory
copier memoryStandard 1, 024MB, max. 2, 048MB
printer memoryStandard 512MB, max. 1, 536MB
HDD80GB
Paper Handling IconPaper Handling
standard paper capacity1, 100 sheets
maximum paper capacity5, 600 sheets
paper weight (tray)60 g/m² to 209 g/m²
Weight and Dimensions IconWeight and Dimensions
dimensions620 x 695 x 950 mm
weightApprox. 112 kg
