MX-3610N SIMULATION 5 – 11
2-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the loads
in the automatic document feeder and the
control circuit.
Section
RSPF
Operation/Procedure
1) Select a target item of the operation check with the touch panel
key.
2) Press [EXECUTE] key.
The selected load performs the operation.
When [EXECUTE] key is pressed, the operation is terminated.
3
3-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and the detectors in the finisher and
the control circuit.
Section
Finisher
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The code names of the sensors and the detectors which are active
are highlighted.
Inner finisher (MX-FN17)
Saddle stitch finisher (MX-FN10)
Display Content
SPUM_F RSPF paper feed motor (normal rotation)
SPUM_R RSPF paper feed motor (reverse rotation)
SPFM_F RSPF transport motor (normal rotation)
SPFM_R RSPF transport motor (reverse rotation)
SPRS Paper exit roller pressure control solenoid (RSPF)
SRRC Registration roller clutch (RSPF)
STMPS Stamp solenoid
Display Content
FABHS Paper alignment belt HP sensor
FAPHPS_F Paper alignment plate HP sensor F
FAPHPS_R Paper alignment plate HP sensor R
FDRPS Paper exit roller position sensor
FDTLLS Paper exit tray lower limit sensor
FDTPD Delivery tray paper detector
FDTULS Paper exit tray upper limit sensor
FFL Fan lock signal
FPCHPS Punch home position sensor
FPD Punch unit detection (connector)
FPDFS Punch dust sensor
FPES1 Punch paper edge sensor 1
FPES2 Punch paper edge sensor 2
FPES3 Punch paper edge sensor 3
FPES4 Punch paper edge sensor 4
FPES5 Punch paper edge sensor 5
FPES6 Punch paper edge sensor 6
FPES7 Punch paper edge sensor 7
FPHPS Punch unit home position sensor
FPLD1 Paper height detector 1
FPLD2 Paper height detector 2
FPMRS Punch motor rotation sensor
FPMS Punch mode sensor
FPPD1 Paper entry detector
FPTS Punch timing sensor
FSED Staple empty detector
FSHPS Staple HP sensor
FSLD Staple lead edge detector
FSSHPS Stapler shift home position sensor
FSSS Staple safety sensor
FSSW Safety switch
FSTPD Staple tray paper detector
FTPS Tray position sensor
FATPD Paper alignment tray paper detector
FCD Connection detector
FCD1 Cover detector 1
FCD2 Cover detector 2
FDRHS Delivery roller home position sensor
FDTPD Delivery tray paper detector
FFL Fan lock signal
FGHPS Gripper home position sensor
FPAPHS_F Paper alignment plate home position sensor F
FPAPHS_R Paper alignment plate home position sensor R
FPCHPS Punch home position sensor
FPD Punch unit detection (connector)
FPDD Delivery detector
FPDFS Punch dust sensor
FPES1 Punch paper edge sensor 1
FPES2 Punch paper edge sensor 2
FPES3 Punch paper edge sensor 3
FPES4 Punch paper edge sensor 4
FPHHS Paper hold home position sensor
FPHPS Punch unit home position sensor
FPLD Paper surface detector
FPMRS Punch motor rotation sensor
FPMS Punch mode sensor
FPPD1 Paper transport detector 1
FPPD2 Paper transport detector 2
FPPD3 Paper transport detector 3
FPTS Punch timing sensor
FSAPHS Saddle alignment plate home position sensor
FSATPD Saddle paper alignment tray paper detector
FSED Staple empty detector
FSHS Staple home position sensor
FSLS Staple lead edge sensor
FSMRS Saddle motor rotation sensor
FSPGHS Saddle paper guide home position sensor
FSPHS Saddle plate home position sensor
FSRHS Saddle roller home position sensor
FSSCS Saddle staple cover sensor
FSSES Saddle staple sensor
FSSHPS Stapler shift home position sensor
FSSHS Saddle staple home position sensor
FSSSHS Saddle stapler shift home position sensor
FSSSW1 Staple safety switch
FSSSW2 Stapler safety switch 2
FSSW1 Safety switch 1
FSTPD Saddle exit tray paper detector
FTLLD Tray lower limit detector
FTLMRS Tray lift motor rotation sensor
FTPS Tray position sensor
FTULD Tray upper limit detector
PDOS Paper pass cover Open/Close sensor
PDPPD1 Paper pass paper transport detector 1
PDPPD2 Paper pass paper transport detector 2
Display Content
