1-62
BEFORE USING THE MACHINE
Contents
CLEANING THE MAIN CHARGER OF THE
PHOTOCONDUCTIVE DRUM
If black lines or colored lines appear even after you have cleaned the document glass and automatic document feeder,
use the charger cleaner to clean the main charger that charges the drum.
1
Open the front cover.
2
Release the waste toner box.
Press the waste toner box release button.
The waste toner box will fall forward as shown.
Gently support the box with your hands as you let it fall forward
as far as it will go.
3
Grasp the green knob to release the lock
and gently remove the charger cleaner.
4
Clean the main charger.
(1) Gently push the charger cleaner all the way
in.
(2) Gently pull the charger cleaner out.
Insert so that the cleaning location label (A) and the charger
cleaner label (B) are oriented as shown.
(B)
(A)
To Next Page
