MX-5001N SIMULATION 6 – 47
[50-sheet machine]
M HL_UM HEAVY PAPER Heavy paper TH_UM set value 70 - 230 185 185 185 185 185 185 –
N HL_LM HEAVY PAPER Heavy paper TH_LM set value 30 - 200 140 140 140 140 140 140 –
O HL_E HEAVY PAPER Heavy paper TH_E set value 70 - 230 220 220 220 220 220 220 –
P HL_UM OHP PAPER OHP-TH_UM set value 70 - 230 180 180 180 180 180 180 –
Q HL_LM OHP PAPER OHP-TH_LM set value 30 - 200 140 140 140 140 140 140 –
R HL_E OHP PAPER OHP-TH_E set value 70 - 230 220 220 220 220 220 220 –
S HL_UM ENV PAPER Envelope TH_UM set value 70 - 230 190 190 190 190 190 190 –
T HL_LM ENV PAPER Envelope TH_LM set value 30 - 200 140 140 140 140 140 140 –
U HL_E ENV PAPER Envelope TH_E set value 70 - 230 220 220 220 220 220 220 –
V HL_UM GLOSS PAPER Glossy paper TH_UM set value 70 - 230 185 185 185 185 185 185 –
W HL_LM GLOSS PAPER Glossy paper TH_LM set value 30 - 200 140 140 140 140 140 140 –
X HL_E GLOSS PAPER Glossy paper TH_E set value 70 - 230 220 220 220 220 220 220 –
Y HL_UM E-STAR Preheating TH_UM set value 30 - 200 150 150 160 160 160 160 {
Z HL_E E-STAR Preheating TH_E set value 30 - 200 150 150 160 160 160 160 {
AA PRE-JOB Resetting from preheating TH_UM, TH_E
set value
30 - 200 170 170 175 175 175 175 {
AB HL_LM E-STAR Preheating TH_LM set value 30 - 200 100 100 100 100 100 100 {
AC HL_UM HEAVY2 PAPER Heavy paper 2 TH_UM set value 0 - 255 200 200 200 200 200 200 –
AD HL_LM HEAVY2 PAPER Heavy paper 2 TH_LM set value 0 - 255 140 140 140 140 140 140 –
AE HL_E HEAVY2 PAPER Heavy paper 2 TH_E set value 0 - 255 220 220 220 220 220 220 –
AF HL_UM WARMUP_120L TH_UM set value when WarmUp at 120°C
or below
70 - 230 175 185 180 185 180 185 {
AG HL_LM WARMUP_120L TH_LM set value when WarmUp at 120°C
or below
30 - 200 120 130 125 130 125 130 {
AH HL_E WARMUP_120L TH_E set value when WarmUp at 120°C or
below
70 - 230 220 225 225 225 225 225 {
AI LO_WARMUP_TIME AF-AH applying time (Timer from
completion of Ready)
0 - 255252525252525 –
AJ HL_UM WARMUP_120H TH_UM set value when WarmUp at 120°C
or above
70 - 230 170 185 180 185 180 185 {
AK HL_LM WARMUP_120H TH_LM set value when WarmUp at 120°C
or above
30 - 200 120 130 125 130 125 130 {
AL HL_E WARMUP_120H TH_E set value when WarmUp at 120°C or
above
70 - 230 220 225 225 225 225 225 {
AM HI_WARMUP_TIME AJ-AL applying time (Timer from
completion of Ready)
0 - 255555555 –
AN HI_WU_FM_ON_TMP FM prior rotation start TH_E when
WarmUp at alpha °C or above
30 - 200 130 130 130 130 130 130 {
AO HI_WU_END_TIME WarmUp completion time when WarmUp
at alpha °C or above
0 - 255454545454545 {
AP HI_WU_JOB_SET_TMP Job enable TH_UM temperature when
WarmUp at alpha °C or above
70 - 230 165 180 175 180 180 180 {
AQ HI_WARMUP_BORDER Threshold value alpha to which SIM43-1-
AN - AP is applied
1 - 119707070707070 –
AR LO_WU_JOB_SET_TMP Job enable TH_UM temperature when
WarmUp at alpha °C or below
70 - 230 175 185 175 185 180 185 {
AS ROT_TIME_AFTER_JOB After rotating time when a job is completed 0 - 255 15 15 15 15 15 15 –
Item/Display Content
Setting
range
Default value
Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
SW-A SW-B SW-A SW-B SW-A SW-B
1
Item/Display Content
Setting
range
Default value
Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
SW-A SW-B SW-A SW-B SW-A SW-B
A HL_UM READY Ready standby TH_UM set value 70 - 230 180 190 185 190 185 190 {
B HL_LM READY Ready standby TH_LM set value 30 - 200 100 115 110 115 110 115 {
C HL_E READY Ready standby TH_E set value 70 - 230 185 195 185 195 195 200 {
D HL_UM PLAIN PAPER BW Black-White plain paper TH_UM set value 70 - 230 190 195 190 195 190 195 {
E HL_LM PLAIN PAPER BW Black-White plain paper TH_LM set value 30 - 200 115 140 130 140 150 150 {
F HL_E PLAIN PAPER BW Black-White plain paper TH_E set value 70 - 230 225 225 225 225 225 225 {
G HL_UM PLAIN PAPER CL Color plain paper TH_UM set value 70 - 230 190 195 190 195 190 195 {
H HL_LM PLAIN PAPER CL Color plain paper TH_LM set value 30 - 200 120 140 130 140 150 150 {
I HL_E PLAIN PAPER CL Color plain paper TH_E set value 70 - 230 225 225 225 225 225 225 {
J WARMUP FUMON HL_E T Fusing motor pre-rotation start TH_E set
value
30 - 200 150 150 150 150 150 150 {
K WARMUP FUMOFF HL_LM T Fusing motor pre-rotation end TH_LM set
value
30 - 200303030303030 {
L WARM UP END TIME Warm-up complete time 30 - 255 135 180 135 180 135 180 {
M HL_UM HEAVY PAPER Heavy paper TH_UM set value 70 - 230 185 185 185 185 185 185 –
N HL_LM HEAVY PAPER Heavy paper TH_LM set value 30 - 200 140 140 140 140 140 140 –
O HL_E HEAVY PAPER Heavy paper TH_E set value 70 - 230 220 220 220 220 220 220 –
: Oct. 24 2008
