MX-5001N SIMULATION 6 – 48
<Code descriptions>
<List of destination groups>
P HL_UM OHP PAPER OHP-TH_UM set value 70 - 230 180 180 180 180 180 180 –
Q HL_LM OHP PAPER OHP-TH_LM set value 30 - 200 140 140 140 140 140 140 –
R HL_E OHP PAPER OHP-TH_E set value 70 - 230 220 220 220 220 220 220 –
S HL_UM ENV PAPER Envelope TH_UM set value 70 - 230 190 190 190 190 190 190 –
T HL_LM ENV PAPER Envelope TH_LM set value 30 - 200 140 140 140 140 140 140 –
U HL_E ENV PAPER Envelope TH_E set value 70 - 230 220 220 220 220 220 220 –
V HL_UM GLOSS PAPER Glossy paper TH_UM set value 70 - 230 185 185 185 185 185 185 –
W HL_LM GLOSS PAPER Glossy paper TH_LM set value 30 - 200 140 140 140 140 140 140 –
X HL_E GLOSS PAPER Glossy paper TH_E set value 70 - 230 220 220 220 220 220 220 –
Y HL_UM E-STAR Preheating TH_UM set value 30 - 200 155 155 155 155 165 165 {
Z HL_E E-STAR Preheating TH_E set value 30 - 200 155 155 155 155 165 165 {
AA PRE-JOB Resetting from preheating TH_UM, TH_E
set value
30 - 200 175 175 180 180 180 180 {
AB HL_LM E-STAR Preheating TH_LM set value 30 - 200 100 100 100 100 100 100 {
AC HL_UM HEAVY2 PAPER Heavy paper 2 TH_UM set value 0 - 255 200 200 200 200 200 200 –
AD HL_LM HEAVY2 PAPER Heavy paper 2 TH_LM set value 0 - 255 140 140 140 140 140 140 –
AE HL_E HEAVY2 PAPER Heavy paper 2 TH_E set value 0 - 255 220 220 220 220 220 220 –
AF HL_UM WARMUP_120L TH_UM set value when WarmUp at 120°C
or below
70 - 230 185 200 190 200 190 200 {
AG HL_LM WARMUP_120L TH_LM set value when WarmUp at 120°C
or below
30 - 200 120 135 130 135 130 135 {
AH HL_E WARMUP_120L TH_E set value when WarmUp at 120°C
or below
70 - 230 190 210 200 210 205 210 {
AI LO_WARMUP_TIME AF-AH applying time (Timer from
completion of Ready)
0 - 255 25 25 25 25 25 25 –
AJ HL_UM WARMUP_120H TH_UM set value when WarmUp at 120°C
or above
70 - 230 185 195 190 195 190 195 {
AK HL_LM WARMUP_120H TH_LM set value when WarmUp at 120°C
or above
30 - 200 120 135 130 135 130 135 {
AL HL_E WARMUP_120H TH_E set value when WarmUp at 120°C
or above
70 - 230 220 225 225 225 225 225 {
AM HI_WARMUP_TIME AJ-AL applying time (Timer from
completion of Ready)
0 - 255555555 –
AN HI_WU_FM_ON_TMP FM prior rotation start TH_E when
WarmUp at alpha °C or above
30 - 200 130 130 130 130 130 130 {
AO HI_WU_END_TIME WarmUp completion time when WarmUp
at alpha °C or above
0 - 255 45 45 45 45 45 45 {
AP HI_WU_JOB_SET_TMP Job enable TH_UM temperature when
WarmUp at alpha °C or above
70 - 230 170 185 180 185 180 185 {
AQ HI_WARMUP_BORDER Threshold value alpha to which SIM43-1-
AN - AP is applied
1 - 119707070707070 –
AR LO_WU_JOB_SET_TMP Job enable TH_UM temperature when
WarmUp at alpha °C or below
70 - 230 185 200 190 200 190 200 {
AS ROT_TIME_AFTER_JOB After rotating time when a job is completed 0 - 255 15 15 15 15 15 15 {
Item/Display Content
Setting
range
Default value
Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
SW-A SW-B SW-A SW-B SW-A SW-B
1
TH_UM Fusing upper thermister main center HL_UM Heater lamp upper main
TH_LM Fusing lower thermister main HL_LM Heater lamp lower main
TH_E Fusing thermister external HL_E Heater lamp external
Group 1 Japan China AB_B
Group 2 U.S.A. Canada Inch
Group 3 Europe U.K. AUS AB_A
SW-A Setting value when plain paper is selected in the system setting/device setting/fusing control setting.
SW-B Set value when heavy paper is selected in the system setting/device setting/fusing control setting.
The set value displayed in this simulation differs depending on plain paper or heavy paper which is selected in the system setting/device setting/fusing
control setting.
(Example) When plain paper is selected in the system setting/device setting/fusing control setting, the value of SW-A is displayed.
NOTE: When the destination is changed with SIM26-6 after changing this set value, the set values of the destination link items are reset to the default.
: Oct. 24 2008
