MX-5001N SIMULATION 6 – 57
* Item L: 1 Count = 1s Change
Correction value for the other items: 1 count for 1°C change
<Code descriptions>
<List of destination groups>
43-22
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environment correction
under low temperature and low humidity (L/
L) for the fusing temperature setting (SIM
43-4) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with [↑] [↓] keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2 is saved.
Correction value: -49 - +49, 1 Count = 1°C Change
AJ HL_UM WARMUP_120H HH Correction value for TH_UM set value in WarmUp at 120°C
or above under HH environment
1 - 99 50 50 50 –
AK HL_LM WARMUP_120H HH Correction value for TH_LM set value in WarmUp at 120°C
or above under HH environment
1 - 99 50 50 50 –
AL HL_E WARMUP_120H HH Correction value for TH_E set value in WarmUp at 120°C or
above under HH environment
1 - 99 50 50 50 –
AM HI_WU_TIME_HH Correction value for AJ-AL applying time (timer from Ready
complete) under HH environment
1 - 99 50 50 50 –
AN HI_WU_FM_ON_TMP_HH Correction value for FM prior rotation start TH_E in WarmUp
at alpha °C or above under HH environment
1 - 99 50 50 50 –
AO HI_WU_END_TIME_HH Correction value for WarmUp completion time in WarmUp at
alpha °C or above under HH environment
1 - 99 50 50 50 –
AP HI_WU_JOB_SET_TMP_HH Correction value for Job Enable TH_UM temperature in
WarmUp at alpha °C or above under HH environment
1 - 99 50 50 50 –
AQ HI_WARMUP_BORDER_HH Correction value for the threshold value alpha applying
SIM43-1-AN - AP under HH environment
1 - 99 50 50 50 –
AR LO_WU_JOB_SET_TMP_HH Correction value for Job Enable TH_UM temperature in
WarmUp at alpha °C or below under HH environment
1 - 99 50 50 50 –
AS ROT_TIME_AFTER_JOB_HH Correction value for the after rotation time when completing
a job under HH environment
1 - 99 50 50 50 –
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
1
TH_UM Fusing upper thermister main center HL_UM Heater lamp upper main
TH_LM Fusing lower thermister main HL_LM Heater lamp lower main
TH_E Fusing thermister external HL_E Heater lamp external
Group 1 Japan China AB_B
Group 2 U.S.A. Canada Inch
Group 3 Europe U.K. AUS AB_A
NOTE: When the destination is changed with SIM26-6 after changing this set value, the set values of the destination link items are reset to the default.
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
)86(57(03$'-8670(17++



$˖
˷˹
˖+/B805($'<++
$˖
˖+/B/05($'<++
%˖
˖+/B(5($'<++
&˖
˖+/B803/$,1%:++
'˖
˖+/B(3/$,1%:++
)˖
˖+/B/03/$,1%:++
(˖
˖+/B803/$,1&/++
*˖
˖+/B/03/$,1&/++
+˖
˖+/B(3/$,1&/++
,˖
˖:$5083)8021+/B(7++
-˖
˖:$5083)802))7++
.˖
˖:$5083(1'7,0(++
/˖
2.
Correction
value
-49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
: Oct. 24 2008
