MX-5001N SIMULATION 6 – 58
[41-sheet machine]
* Items D, H: 1 Count = 1s Change
Correction value for the other items: 1 count for 1°C change
[50-sheet machine]
1
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
A HL_UM PLAIN BW DUP LL Correction value for upper TH_UM Black-White plain paper
duplex under LL environment
1 - 99 55 55 55 {
B HL_LM PLAIN BW DUP LL Correction value for lower TH_LM Black-White plain paper
duplex under LL environment
1 - 99 55 55 55 {
C HL_E PLAIN BW DUP LL Correction value for upper TH_E Black-White plain paper
duplex under LL environment
1 - 99 55 55 55 {
D PLAIN BW DUP APP CNT LL Correction value for applying number of sheets in Black-
White plain paper duplex under LL environment
1 - 99 50 50 50 {
E HL_UM PLAIN CL DUP LL Correction value for upper TH_UM Color plain paper duplex
under LL environment
1 - 99 55 55 55 {
F HL_LM PLAIN CL DUP LL Correction value for lower TH_LM Color plain paper duplex
under LL environment
1 - 99 55 55 55 {
G HL_E PLAIN CL DUP LL Correction value for upper TH_E Color plain paper duplex
under LL environment
1 - 99 50 50 50 {
H PLAIN CL DUP APP CNT LL Correction value for applying number of sheets in Color
plain paper duplex under LL environment
1 - 99 50 50 50 {
I HL_UM HEAVY BW DUP LL Correction value for upper TH_UM set value in Black-White
heavy paper duplex under LL environment
1 - 99 55 55 55 –
J HL_LM HEAVY BW DUP LL Correction value for lower TH_LM set value in Black-White
heavy paper duplex under LL environment
1 - 99 55 55 55 –
K HL_E HEAVY BW DUP LL Correction value for upper TH_E set value in Black-White
heavy paper duplex under LL environment
1 - 99 55 55 55 –
L HEAVY BW DUP APP CNT LL Correction value for applying number of sheets in Black-
White heavy paper duplex under LL environment
1 - 99 50 50 50 –
M HL_UM HEAVY CL DUP LL Correction value for upper TH_UM set value in Color heavy
paper duplex under LL environment
1 - 99 55 55 55 –
N HL_LM HEAVY CL DUP LL Correction value for lower TH_LM set value in Color heavy
paper duplex under LL environment
1 - 99 55 55 55 –
O HL_E HEAVY CL DUP LL Correction value for upper TH_E set value in Color heavy
paper duplex under LL environment
1 - 99 50 50 50 –
P HEAVY CL DUP APP CNT LL Correction value for applying number of sheets in Color
heavy paper duplex under LL environment
1 - 99 50 50 50 –
1
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
A HL_UM PLAIN BW DUP LL Correction value for upper TH_UM Black-White plain paper
duplex under LL environment
1 - 99 55 55 55 {
B HL_LM PLAIN BW DUP LL Correction value for lower TH_LM Black-White plain paper
duplex under LL environment
1 - 99 55 55 55 {
C HL_E PLAIN BW DUP LL Correction value for upper TH_E Black-White plain paper
duplex under LL environment
1 - 99 55 55 55 {
D PLAIN BW DUP APP CNT LL Correction value for applying number of sheets in Black-
White plain paper duplex under LL environment
1 - 99 50 50 50 {
E HL_UM PLAIN CL DUP LL Correction value for upper TH_UM Color plain paper duplex
under LL environment
1 - 99 55 55 55 {
F HL_LM PLAIN CL DUP LL Correction value for lower TH_LM Color plain paper duplex
under LL environment
1 - 99 55 55 55 {
G HL_E PLAIN CL DUP LL Correction value for upper TH_E Color plain paper duplex
under LL environment
1 - 99 50 50 50 {
H PLAIN CL DUP APP CNT LL Correction value for applying number of sheets in Color
plain paper duplex under LL environment
1 - 99 50 50 50 {
I HL_UM HEAVY BW DUP LL Correction value for upper TH_UM set value in Black-White
heavy paper duplex under LL environment
1 - 99 55 55 55 –
J HL_LM HEAVY BW DUP LL Correction value for lower TH_LM set value in Black-White
heavy paper duplex under LL environment
1 - 99 55 55 55 –
K HL_E HEAVY BW DUP LL Correction value for upper TH_E set value in Black-White
heavy paper duplex under LL environment
1 - 99 55 55 55 –
L HEAVY BW DUP APP CNT LL Correction value for applying number of sheets in Black-
White heavy paper duplex under LL environment
1 - 99 50 50 50 –
M HL_UM HEAVY CL DUP LL Correction value for upper TH_UM set value in Color heavy
paper duplex under LL environment
1 - 99 55 55 55 –
N HL_LM HEAVY CL DUP LL Correction value for lower TH_LM set value in Color heavy
paper duplex under LL environment
1 - 99 55 55 55 –
O HL_E HEAVY CL DUP LL Correction value for upper TH_E set value in Color heavy
paper duplex under LL environment
1 - 99 50 50 50 –
