MX-5001N SIMULATION 6 – 59
* Items D, H: 1 Count = 1s Change
Correction value for the other items: 1 count for 1°C change
<Code descriptions>
<List of destination groups>
43-23
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environment correction
under high temperature and high humidity
(H/H) for the fusing temperature setting
(SIM 43-4) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with [↑] [↓] keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
Correction value: -49 - +49, 1 Count = 1°C Change
[41-sheet machine]
P HEAVY CL DUP APP CNT LL Correction value for applying number of sheets in Color
heavy paper duplex under LL environment
1 - 99 50 50 50 –
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
1
TH_UM Fusing upper thermister main center HL_UM Heater lamp upper main
TH_LM Fusing lower thermister main HL_LM Heater lamp lower main
TH_E Fusing thermister external HL_E Heater lamp external
Group 1 Japan China AB_B
Group 2 U.S.A. Canada Inch
Group 3 Europe U.K. AUS AB_A
NOTE: When the destination is changed with SIM26-6 after changing this set value, the set values of the destination link items are reset to the default.
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
)86(57(03$'-8670(17//'83
$˖
˷˹
˖+/B803/$,1%:'83//
$˖
˖+/B/0ǂ3/$,1%:'83//
%˖
˖+/B(3/$,1%:'83//
&˖
˖3/$,1%:'83ǂ$33ǂ&17//
'˖
˖+/B/0ǂ3/$,1&/'83//
)˖
˖+/B80ǂ3/$,1&/'83//
(˖
˖+/B(ǂ3/$,1&/'83//
*˖
˖3/$,1&/'83ǂ$33ǂ&17//
+˖
˖+/B80+($9<%:'83//
,˖
˖+/B/0+($9<%:'83//
-˖
˖+/B(+($9<%:'83//
.˖
˖+($9<%:'83$33&17//
/˖
2.
Correction
value
-49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
1
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
A HL_UM PLAIN BW DUP HH Correction value for TH_UM Black-White plain paper
duplex mode under HH environment
1 - 99 50 50 50 {
B HL_LM PLAIN BW DUP HH Correction value for TH_LM Black-White plain paper
duplex mode under HH environment
1 - 99 50 50 50 {
C HL_E PLAIN BW DUP HH Correction value for TH_E Black-White plain paper duplex
mode under HH environment
1 - 99 50 50 50 {
D PLAIN BW DUP APP CNT HH Correction value for applying number of sheets in
Black-White plain paper duplex under HH environment
1 - 99 50 50 50 {
E HL_UM PLAIN CL DUP HH Correction value for TH_UM Color plain paper duplex
mode under HH environment
1 - 99 50 50 50 {
F HL_LM PLAIN CL DUP HH Correction value for TH_LM Color plain paper duplex
mode under HH environment
1 - 99 50 50 50 {
G HL_E PLAIN CL DUP HH Correction value for TH_E Color plain paper duplex mode
under HH environment
1 - 99 50 50 50 {
H PLAIN CL DUP APP CNT HH Correction value for applying number of sheets in
Color plain paper duplex under HH environment
1 - 99 50 50 50 {
: Oct. 24 2008
