MX-5001N SIMULATION 6 – 65
44-6
Purpose
Adjustment
Function (Purpose)
Used to execute the high density process
control forcibly.
Section
Process
Operation/Procedure
Press [EXECUTE] key.
In case of a normal completion, the result is saved.
In case of an abnormal completion, "ERROR" is displayed.
(Refer to the table below.)
In case of an ERROR, the previous correction data are saved.
44-9
Purpose
Operation data display
Function (Purpose)
Used to display the result data of the high
density process control operation.
Section
Image process (Photoconductor/Develop-
ing/Transfer/Cleaning)
Operation/Procedure
Select a target display mode with [CPY/PRN],[OTHER] keys.
M K_PAT TARGET ID Patch density
standard value
(black)
1 - 255 5
N HV BK_GROUND
LIMIT
Patch position
substrate light
receiving effective
range value
1 - 255 60
Item/Display Content
Setting
range
Default
value
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
352&21,1,7,$/'(16,7<6(783



$˖
˷
˹
˖3&6B&/7$5*(7
$˖

˖3&6B.7$5*(7
%˖

˖/('B&/287387
&˖

˖/('B.287387
'˖

˖%(/7*5281'',)
)˖

˖3&6$'-670(17/,0,7
(˖

˖%,$6B&/67$1'$5'',)
*˖

˖%,$6B%.67$1'$5'',)
+˖

˖%,$63$7&+,17(59$/
,˖

˖<B3$77$5*(7,'
-˖

˖0B3$77$5*(7,'
.˖

˖&B3$77$5*(7,'
/˖

2.
Result display Content description
COMPLETE Normal complete
ERROR Abnormal end
INTERRUPTION Forcible interruption
Details of error display Content description
CL_SEN_ADJ_ERR Color sensor adjustment abnormality
BK_SEN_ADJ_ERR Black sensor adjustment abnormality
K_HV_ERR K high density process control abnormality
C_HV_ERR C high density process control abnormality
M_HV_ERR M high density process control abnormality
Y_HV _ERR Y high density process control abnormality
TIMEOUT_ERR Time out
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
352&21&2038/625<(;(&87,21


(;(&87(
35(66>(;(&87(@7267$57
Mode Item/Display (*: Correction value) Content Display range
Default
value
CPY/PRN P (PROCON) BLACK : GB ***/*** DV ***/*** High density process control GB/DV data
(KCMY)
(Actual output voltage level/base voltage
level)
GB: 230 - 850
DV: 0 - 700
GB: 630
DV: 430
CYAN : GB ***/*** DV ***/***
MAGENTA : GB ***/*** DV ***/***
YELLOW : GB ***/*** DV ***/***
N(M)
(NORMAL (MIDDLE))
BLACK : GB ***/*** DV ***/*** High density normal (Medium speed
display) GB/DV data (KCMY)
(Actual output voltage level/base voltage
level)
GB: 230 - 850
DV: 0 - 700
GB: 630
DV: 430
CYAN : GB ***/*** DV ***/***
MAGENTA : GB ***/*** DV ***/***
YELLOW : GB ***/*** DV ***/***
N(L)
(NORMAL (LOW))
BLACK : GB ***/*** DV ***/*** High density normal (Low speed display)
GB/DV data (KCMY)
(Actual output voltage level/base voltage
level)
GB: 230 - 850
DV: 0 - 700
GB: 600
DV: 400
CYAN : GB ***/*** DV ***/***
MAGENTA : GB ***/*** DV ***/***
YELLOW : GB ***/*** DV ***/***
