Sharp MX-5001N - Page 211

MX-5001N SIMULATION 6 – 64
44-4
Purpose
Setting
Function (Purpose)
Used to set the conditions of the high den-
sity process control operation.
Section
Process
Operation/Procedure
1) Select an item to be set with [↑] [↓] keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
NOTE: Set the items to the default values unless a change is spe-
cially required.
G PCS_K BELT MIN Belt substrate input
min. value
0 - 255 0
H PCS_K BELT DIF Belt substrate input
difference
(Item E - Item F)
0 - 255 0
I REG_F LED ADJ Registration sensor
light emitting
quantity adjustment
value F
1 - 255 56
J REG_F DARK Registration sensor
dark voltage F
0 - 255 0
K REG_F GRND Belt substrate when
the item I adjustment
is completed.
0 - 255 0
L REG_R LED ADJ Registration sensor
light emitting
quantity adjustment
value R
1 - 255 56
M REG_R DARK Registration sensor
dark voltage R
0 - 255 0
N REG_R GRND Belt substrate when
the item J adjust-
ment is completed.
0 - 256 0
O REG_F BELT MAX Belt substrate input
max. value (F side)
0 - 255 0
P REG_F BELT MIN Belt substrate input
min. value (F side)
0 - 255 0
Q REG_F BELT DIF Belt substrate input
difference
(Item O - Item P)
0 - 255 0
R REG_R BELT MAX Belt substrate input
max. value (R side)
0 - 255 0
S REG_R BELT MIN Belt substrate input
min. value (R side)
0 - 255 0
T REG_R BELT DIF Belt substrate input
difference
(Item R - Item S)
0 - 255 0
U REG_F PATCH (K) Patch light receiving
potential F(K)
0 - 255 0
V REG_F PATCH (C) Patch light receiving
potential F(C)
0 - 255 0
W REG_F PATCH (M) Patch light receiving
potential F(M)
0 - 255 0
X REG_F PATCH (Y) Patch light receiving
potential F(Y)
0 - 255 0
Y REG_R PATCH (K) Patch light receiving
potential R(K)
0 - 255 0
Z REG_R PATCH (C) Patch light receiving
potential R(C)
0 - 255 0
AA REG_R PATCH (M) Patch light receiving
potential R(M)
0 - 255 0
AB REG_R PATCH (Y) Patch light receiving
potential R(Y)
0 - 255 0
Error name Error content
Black sensor adjustment
abnormality
PCS_K LED ADJ error
The target is not reached by 3 times of
retry.
Color sensor adjustment
abnormality
PCS_CL LED ADJ error
The target is not reached by 3 times of
retry.
Substrate scan abnormality PCS_K GRND error
Effective difference between the upper
and lower values of the belt substrate
circuit, outside the range
Registration sensor F
adjustment abnormality
REG_F LED ADJ error
The target is not reached by 3 times of
retry.
Registration sensor R
adjustment abnormality
REG_R LED ADJ error
The target is not reached by 3 times of
retry.
Item/Display Content
Setting
range
Default
value
Registration substrate F
scan abnormality
REG_F GRND error
Effective difference between the upper
and lower values of the belt substrate
circuit, outside the range
Registration substrate R
scan abnormality
REG_R GRND error
Effective difference between the upper
and lower values of the belt substrate
circuit, outside the range
Item/Display Content
Setting
range
Default
value
A PCS_CL TARGET Color sensor target
set value
1 - 255 98
B PCS_K TARGET Black sensor target
set value
1 - 255 208
C LED_CL OUTPUT Color sensor light
emitting quantity set
value
1 - 255 21
D LED_K OUTPUT Black sensor light
emitting quantity set
value
1 - 255 21
E PCS ADJSTMENT
LIMIT
Sensor adjustment
target limit value
1 - 255 4
F BELT GROUND DIF Effective difference
between the belt 1
circuit substrate
upper and lower limit
values
1 - 255 1
G BIAS_CL
STANDARD DIF
Bias (for color)
reference calculation
difference
0 - 255 60
H BIAS_BK
STANDARD DIF
Bias (for black)
reference calculation
difference
0 - 255 0
I BIAS PATCH
INTERVAL
Patch bias output
interval
1 - 255 60
J Y_PAT TARGET ID Patch density
standard value
(yellow)
1 - 255 122
K M_PAT TARGET ID Patch density
standard value
(magenta)
1 - 255 132
L C_PAT TARGET ID Patch density
standard value
(cyan)
1 - 255 118
Error name Error content
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
352&21*$,1$'-8670(17



(;(&87(
3&6B&//('$'- 5(*B5/('$'-
3&6B./('$'- 5(*B5'$5.
3&6B&/'$5. 5(*B5*51'
3&6B.'$5.
3&6B.*51' 5(*B)%(/70$;
3&6B.%(/70$; 5(*B)%(/70,1
3&6B.%(/70,1 5(*B)%(/7',)
3&6B.%(/7',)
5(*B)/('$'- 5(*B5%(/70$;
5(*B)'$5. 5(*B5%(/70,1
5(*B)*51' 5(*B5%(/7',)
