MX-5001N SIMULATION 6 – 86
To check the adjustment density level of items A - L, set the docu-
ment and set the setting value of item M according to items A - L,
and press [EXECUTE] key.
46-43
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the FAX send image density.
(Super Fine)
Section
Operation/Procedure
1) Set the original on the original table.
2) Enter the set value with 10-key.
3) Press [EXECUTE] key, or [OK] key
When [EXECUTE] key is pressed, the adjustment value is set
and the scanned document image is outputted.
To check the adjustment density level of items A - L, set the docu-
ment and set the setting value of item M according to items A - L,
and press [EXECUTE] key.
H EXPOSURE1 H_TONE Fine/Exposure 1/
Half tone
1 - 99 50
I EXPOSURE2 H_TONE Fine/Exposure 2/
Half tone
1 - 99 50
J EXPOSURE3 H_TONE Fine/Exposure 3/
Half tone
1 - 99 50
K EXPOSURE4 H_TONE Fine/Exposure 4/
Half tone
1 - 99 50
L EXPOSURE5 H_TONE Fine/Exposure 5/
Half tone
1 - 99 50
M EXECUTE
MODE
AUTO Print
mode
Fine/Auto 1 -
12
11
(AUTO)
EXP1 Fine/
Exposure 1
2
EXP2 Fine/
Exposure 2
3
EXP3 Fine/
Exposure 3
4
EXP4 Fine/
Exposure 4
5
EXP5 Fine/
Exposure 5
6
AUTO
H_TONE
Fine/
Automatic/
halftone
7
EXP1
H_TONE
Fine/
Exposure 1
/Half tone
8
EXP2
H_TONE
Fine/
Exposure 2
/Half tone
9
EXP3
H_TONE
Fine/
Exposure 3
/Half tone
10
EXP4
H_ONE
Fine/
Exposure 4
/Half tone
11
EXP5
H_TONE
Fine/
Exposure 5
/Half tone
12
Item/Display Content
Setting
range
Default
value
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
(;32685($'-8670(17)$;),1(


$˖
˷˹
˖$872
$˖
˖(;32685(
%
˖
˖(;32685(
&˖
˖(;32685(
'˖
˖(;32685(
)˖
˖(;32685(
(˖
˖$872+B721(
*
˖
˖(;32685(+B721(
+˖
˖(;32685(+B721(
,˖
˖(;32685(+B721(
-˖
˖(;32685(+B721(
.˖
˖(;32685(+B721(
/˖
2.
(;(&87(
Item/Display Content
Setting
range
Default
value
A AUTO Super Fine/Auto 1 - 99 50
B EXPOSURE1 Super Fine/Exposure 1 1 - 99 50
C EXPOSURE2 Super Fine/Exposure 2 1 - 99 50
D EXPOSURE3 Super Fine/Exposure 3 1 - 99 50
E EXPOSURE4 Super Fine/Exposure 4 1 - 99 50
F EXPOSURE5 Super Fine/Exposure 5 1 - 99 50
G AUTO H_TONE Super Fine
/Auto/Half tone
1 - 99 50
H EXPOSURE1
H_TONE
Super Fine/Exposure 1
/Half tone
1 - 99 50
I EXPOSURE2
H_TONE
Super Fine/Exposure 2
/Half tone
1 - 99 50
J EXPOSURE3
H_TONE
Super Fine/Exposure 3
/Half tone
1 - 99 50
K EXPOSURE4
H_TONE
Super Fine/Exposure 4
/Half tone
1 - 99 50
L EXPOSURE5
H_TONE
Super Fine/Exposure 5
/Half tone
1 - 99 50
M EXECUTE
MODE
AUTO Print
mode
Super Fine
/Auto
1 -
12
11
(AUTO)
EXP1 Super Fine
/Exposure 1
2
EXP2 Super Fine
/Exposure 2
3
EXP3 Super Fine
/Exposure 3
4
EXP4 Super Fine
/Exposure 4
5
EXP5 Super Fine
/Exposure 5
6
AUTO
H_TONE
Super Fine
/Auto
/Half tone
7
EXP1
H_TONE
Super Fine
/Exposure 1
/Half tone
8
EXP2
H_TONE
Super Fine
/Exposure 2
/Half tone
9
EXP3
H_TONE
Super Fine
/Exposure 3
/Half tone
10
EXP4
H_TONE
Super Fine
/Exposure 4
/Half tone
11
EXP5
H_TONE
Super Fine
/Exposure 5
/Half tone
12
