Sharp MX-5001N - Page 252

To Next Page

To Previous Page

MX-5001N SIMULATION 6 – 105

Error

code

Error display Error content Description

Forcible

end error

- SUSPENDED Door open end Door open during

operation

- SUSPENDED CA end CA button pressed

during operation

- - OFF end Unconfirmed

operation during

operation

(Power OFF)

Basic

error

1 TONNER

EMPTY 01

Toner Empty BK or ALL Color

toner EMPTY

detection

2 BEFORE

BEHAVIOR

Other

condition

Other condition

4 SENSOR

CALIBRATIO

N 04

Calibration

error

The target is not

reached by 3 times

of retry of F or R

5 TIME OVER

Time error No data are

obtained for 90sec

from data

acquisition

7 PROCESS

CONTROL 07

Process

control error

Process control

error detection

Sub

scanning

adjust-

ment

error

10 SUB BLACK

FRONT 10

Number of line

error sub

scanning color

(Black) F

The pitch data

number are not the

specified value.

11 SUB BLACK

FRONT 11

Pitch error sub

scanning color

(Black) F

The pitch data are

not within the

allowable range.

15 SUB BLACK

REAR 15

Number of line

error sub

scanning color

(Black) R

The pitch data are

not within the

specified range.

16 SUB BLACK

REAR 16

Pitch error sub

scanning color

(Black) R

The pitch data are

not within the

allowable range.

20 SUB CYAN

FRONT 20

Number of line

error sub

scanning color

(Cyan) F

The pitch data

number are not the

specified value.

21 SUB CYAN

FRONT 21

Pitch error sub

scanning color

(Cyan) F

The pitch data are

not within the

allowable range.

22 SUB CYAN

FRONT 22

Adjustment

value number

error sub

scanning color

(Cyan) F

The calculation

result value is not

within the

allowable range.

23 SUB CYAN

FRONT 23

Result value

error sub

scanning color

(Cyan) F

The variation in the

calculation result

value is above the

allowable range.

25 SUB CYAN

REAR 25

Number of

lines error sub

scanning color

(Cyan) R

The pitch data

number are not the

specified value.

26 SUB CYAN

REAR 26

Pitch error sub

scanning color

(Cyan) R

The pitch data are

not within the

allowable range.

Sub

scanning

adjust-

ment

error

27 SUB CYAN

REAR 27

Adjustment

value number

error sub

scanning color

(Cyan) R

The calculation

result value is not

within the

allowable range.

28 SUB CYAN

REAR 28

Result value

error sub

scanning color

(Cyan) R

The variation in the

calculation result

value is above the

allowable range.

30 SUB

MAGENTA

FRONT 30

Number of

lines error sub

scanning color

(Magenta) F

The pitch data

number are not the

specified value.

31 SUB

MAGENTA

FRONT 31

Pitch error sub

scanning color

(Magenta) F

The pitch data are

not within the

allowable range.

32 SUB

MAGENTA

FRONT 32

Adjustment

value number

error sub

scanning color

(Magenta) F

The calculation

result value is not

within the

allowable range.

33 SUB

MAGENTA

FRONT 33

Result value

error sub

scanning color

(Magenta) F

The variation in the

calculation result

value is above the

allowable range.

35 SUB

MAGENTA

REAR 35

Number of

lines error sub

scanning color

(Magenta) R

The pitch data

number are not the

specified value.

36 SUB

MAGENTA

REAR 36

Pitch error sub

scanning color

(Magenta) R

The pitch data are

not within the

allowable range.

37 SUB

MAGENTA

REAR 37

Adjustment

value number

error sub

scanning color

(Magenta) R

The calculation

result value is not

within the

allowable range.

38 SUB

MAGENTA

REAR 38

Result value

error sub

scanning color

(Magenta) R

The variation in the

calculation result

value is above the

allowable range.

40 SUB

YELLOW

FRONT 40

Number of

lines error sub

scanning color

(Yellow) F

The pitch data

number are not the

specified value.

41 SUB

YELLOW

FRONT 41

Pitch error sub

scanning color

(Yellow) F

The pitch data are

not within the

allowable range.

42 SUB

YELLOW

FRONT 42

Adjustment

value number

error sub

scanning color

(Yellow) F

The calculation

result value is not

within the

allowable range.

43 SUB

YELLOW

FRONT 43

Result value

error sub

scanning color

(Yellow) F

The variation in the

calculation result

value is above the

allowable range.

45 SUB

YELLOW

REAR 45

Number of

lines error sub

scanning color

(Yellow) R

The pitch data

number are not the

specified value.

46 SUB

YELLOW

REAR 46

Pitch error sub

scanning color

(Yellow) R

The pitch data are

not within the

allowable range.

47 SUB

YELLOW

REAR 47

Adjustment

value number

error sub

scanning color

(Yellow) R

The calculation

result value is not

within the

allowable range.

48 SUB

YELLOW

REAR 48

Result value

error sub

scanning color

(Yellow) R

The variation in the

calculation result

value is above the

allowable range.

Error

code

Error display Error content Description
