MX-5001N SIMULATION 6 – 106
Main
scanning
adjust-
ment
error
50 MAIN BLACK
FRONT 50
Number of
lines error
main scanning
color (Black) F
The pitch data
number are not the
specified value.
51 MAIN BLACK
FRONT 51
Pitch error
main scanning
color (Black) F
The pitch data are
not within the
allowable range.
55 MAIN BLACK
REAR 55
Number of
lines error
main scanning
color (Black) R
The pitch data are
not within the
specified range.
56 MAIN BLACK
REAR 56
Pitch error
main scanning
color (Black) R
The pitch data are
not within the
allowable range.
60 MAIN CYAN
FRONT 60
Number of
lines error
main scanning
color (Cyan) F
The pitch data
number are not the
specified value.
61 MAIN CYAN
FRONT 61
Pitch error
main scanning
color (Cyan) F
The pitch data are
not within the
allowable range.
62 MAIN CYAN
FRONT 62
Adjustment
value number
error main
scanning color
(Cyan) F
The calculation
result value is not
within the
allowable range.
63 MAIN CYAN
FRONT 63
Result value
error main
scanning color
(Cyan) F
The variation in the
calculation result
value is above the
allowable range.
65 MAIN CYAN
REAR 65
Number of
lines error
main scanning
color (Cyan) R
The pitch data
number are not the
specified value.
66 MAIN CYAN
REAR 66
Pitch error
main scanning
color (Cyan) R
The pitch data are
not within the
allowable range.
67 MAIN CYAN
REAR 67
Adjustment
value error
main scanning
color (Cyan) R
The calculation
result value is not
within the
allowable range.
68 MAIN CYAN
REAR 68
Result value
error main
scanning color
(Cyan) R
The variation in the
calculation result
value is above the
allowable range.
70 MAIN
MAGENTA
FRONT 70
Number of
lines error
main scanning
color
(Magenta) F
The pitch data
number are not the
specified value.
71 MAIN
MAGENTA
FRONT 71
Pitch error
main scanning
color
(Magenta) F
The pitch data are
not within the
allowable range.
72 MAIN
MAGENTA
FRONT 72
Adjustment
value number
error main
scanning color
(Magenta) F
The calculation
result value is not
within the
allowable range.
73 MAIN
MAGENTA
FRONT 73
Result value
error main
scanning color
(Magenta) F
The variation in the
calculation result
value is above the
allowable range.
75 MAIN
MAGENTA
REAR 75
Number of
lines error
main scanning
color
(Magenta) R
The pitch data
number are not the
specified value.
76 MAIN
MAGENTA
REAR 76
Pitch error
main scanning
color
(Magenta) R
The pitch data are
not within the
allowable range.
Error
code
Error display Error content Description
Main
scanning
adjust-
ment
error
77 MAIN
MAGENTA
REAR 77
Adjustment
value error
main scanning
color
(Magenta) R
The calculation
result value is not
within the
allowable range.
78 MAIN
MAGENTA
REAR 78
Result value
error main
scanning color
(Magenta) R
The variation in the
calculation result
value is above the
allowable range.
80 MAIN
YELLOW
FRONT 80
Number of
lines error
main scanning
color (Yellow)
F
The pitch data
number are not the
specified value.
81 MAIN
YELLOW
FRONT 81
Pitch error
main scanning
color (Yellow)
F
The pitch data are
not within the
allowable range.
82 MAIN
YELLOW
FRONT 82
Adjustment
value error
main scanning
color (Yellow)
F
The calculation
result value is not
within the
allowable range.
83 MAIN
YELLOW
FRONT 83
Result value
error main
scanning color
(Yellow) F
The variation in the
calculation result
value is above the
allowable range.
85 MAIN
YELLOW
REAR 85
Number of
lines error
main scanning
color (Yellow)
R
The pitch data
number are not the
specified value.
86 MAIN
YELLOW
REAR 86
Pitch error
main scanning
color (Yellow)
R
The pitch data are
not within the
allowable range.
87 MAIN
YELLOW
REAR 87
Adjustment
value error
main scanning
color (Yellow)
R
The calculation
result value is not
within the
allowable range.
88 MAIN
YELLOW
REAR 88
Result value
error main
scanning color
(Yellow) R
The variation in the
calculation result
value is above the
allowable range.
Others 99 OTHER 99 Other errors Other errors
Error
code
Error display Error content Description
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
$872$'-8670(172)5(*,675$7,21'580326,7,21

0$,1)0$,1568%6.(:
&/1*
0/1*
</1*
3+$6(
&
0
<
(;(&87(
'580326
5(*,67
$//

