MX-5001N SIMULATION 6 – 107
50-24
Purpose
(This simulation is normally not used in the
market.)
Function (Purpose)
Used to display the detail data of SIM 44-2,
50-20, 21 and 22.
Section
Operation/Procedure
NOTE: This simulation is mainly used by the technical division, and
is not necessary for the market.
Item
classific
ation
Display Item content
Setting
range
Related
SIM
Regist-
ration
adjust-
ment
status
check
REG_EXE_CNT Number of
executions of
the registration
adjustment
(Auto
execution)
0 - 99999999 50-22
REG_SUC_CNT Number of
success of the
registration
adjustment
(Auto
execution)
0 - 99999999 50-22
REG_CNT Registration
adjustment
registration
counter
0 - 99999999 -
REG_M_F
(VALUE)
Calculated
correction
amount in the
main scan
direction F in
the auto
registration
adjustment
1.0 - 199.0
(±0.1 unit)
50-22
REG_M_R
(VALUE)
Calculated
correction
amount in the
main scan
direction R in
the auto
registration
adjustment
1.0 - 199.0
(±0.1 unit)
50-22
REG_SUB
(VALUE)
Calculated
correction
amount in the
sub scan
direction in the
automatic
registration
adjustment
1.0 - 199.0
(±0.1 unit)
50-22
REG_M_F (DIF) Registration
value
correction
amount from
the previous
time, main
scan F
-199.0 -
199.0 (±0.1
unit)
50-20,
22
REG_M_R (DIF) Registration
value
correction
amount from
the previous
time, main
scan R
-199.0 -
199.0 (±0.1
unit)
50-20,
22
REG_SUB (DIF) Registration
value
correction
amount from
the previous
time, sub scan
-199.0 -
199.0 (±0.1
unit)
50-21,
22
Phase
adjust-
ment
status
check
PHASE_ADJ (C)
(50-sheet
machine)
Phase
adjustment
(1: This time
value,
2: Previous
time value)
1 - 8 50-22
PHASE_ADJ
(M)
(50-sheet
machine)
Phase
adjustment
(1: This time
value,
2: Previous
time value)
1 - 8 50-22
PHASE_ADJ (Y)
(50-sheet
machine)
Phase
adjustment
(1: This time
value,
2: Previous
time value)
1 - 8 50-22
PHASE_ADJ
(41-sheet
machine)
Phase
adjustment
(1: This time
value,
2: Previous
time value)
1 - 8 50-22
PHASE_STATE Phase state
(1: This time
value,
2: Previous
time value)
1 - 8 50-22
PHASE_LEVEL Phase
deflection level
(before
weighting)
0-99.9
(±0.1 unit)
50-22
PHASE
_WEIGHT
Phase
deflection level
(after
weighting)
(1: This time
value,
2: Previous
time value)
0-99.9
(±0.1 unit)
50-22
Sensor
calibra-
tion
status
check
REG_LED (F) Registration
sensor current
light emitting
value F
1 - 255 44-02,
70-11,
50-22
REG_LED (R) Registration
sensor current
light emitting
value R
1 - 255 44-02,
70-11,
50-22
REG_V (F) Registration
sensor current
light receiving
value F
0 - 255 44-02,
70-11,
50-22
REG_V (R) Registration
sensor current
light receiving
value R
0 - 255 44-02,
70-11,
50-22
REG_DARK (F) Registration
sensor dark
potential F
0 - 255 44-02,
70-11,
50-22
REG_DARK (R) Registration
sensor dark
potential R
0 - 255 44-02,
70-11,
50-22
Sampling
status
check (1)
START_SUB
(F)_U
Sampling start
value Sub scan
F (Rising)
-300.00 -
300.00
(±0.01 unit)
50-22
START_SUB
(F)_D
Sampling start
value Sub scan
F (Falling)
-300.00 -
300.00
(±0.01 unit)
50-22
START_SUB
(R)_U
Sampling start
value Sub scan
R (Rising)
-300.00 -
300.00
(±0.01 unit)
50-22
START_SUB
(R)_D
Sampling start
value Sub scan
R (Falling)
-300.00 -
300.00
(±0.01 unit)
50-22
Item
classific
ation
Display Item content
Setting
range
Related
SIM
1
