MX-5001N SIMULATION 6 – 108
Sampling
status
check (1)
START_MAIN
(F)_U
Sampling start
value Main
scan F (Rising)
-300.00 -
300.00
(±0.01 unit)
50-22
START_MAIN
(F)_D
Sampling start
value Main
scan F (Falling)
-300.00 -
300.00
(±0.01 unit)
50-22
START_MAIN
(R)_U
Sampling start
value Main
scan R (Rising)
-300.00 -
300.00
(±0.01 unit)
50-22
START_MAIN
(R)_D
Sampling start
value Main
scan R
(Falling)
-300.00 -
300.00
(±0.01 unit)
50-22
STD_PITCH
_SUB (F)_U
Sampling
reference pitch
Sub scan F
(Rising)
-50.00-50.00
(±0.01unit)
50-22
STD_PITCH
_SUB (F)_D
Sampling
reference pitch
Sub scan F
(Falling)
-50.00-50.00
(±0.01unit)
50-22
STD_PITCH
_SUB (R)_U
Sampling
reference pitch
Sub scan R
(Rising)
-50.00-50.00
(±0.01unit)
50-22
STD_PITCH
_SUB (R)_D
Sampling
reference pitch
Sub scan R
(Falling)
-50.00-50.00
(±0.01unit)
50-22
STD_PITCH
_MAIN (F)_U
Sampling
reference pitch
Main scan F
(Rising)
-50.00-50.00
(±0.01unit)
50-22
STD_PITCH
_MAIN (F)_D
Sampling
reference pitch
Main scan F
(Falling)
-50.00-50.00
(±0.01unit)
50-22
STD_PITCH
_MAIN (R)_U
Sampling
reference pitch
Main scan R
(Rising)
-50.00-50.00
(±0.01unit)
50-22
STD_PITCH
_MAIN (R)_D
Sampling
reference pitch
Main scan R
(Falling)
-50.00-50.00
(±0.01unit)
50-22
TOTAL_PITCH
_SUB (F)_U
Sampling
reference pitch
all-color
average value
Sub scan F
(Rising)
-50.00-50.00
(±0.01unit)
50-22
TOTAL_PITCH
_SUB (F)_D
Sampling
reference pitch
all-color
average value
Sub scan F
(Falling)
-50.00-50.00
(±0.01unit)
50-22
TOTAL_PITCH
_SUB (R)_U
Sampling
reference pitch
all-color
average value
Sub scan R
(Rising)
-50.00-50.00
(±0.01unit)
50-22
TOTAL_PITCH
_SUB (R)_D
Sampling
reference pitch
all-color
average value
Sub scan R
(Falling)
-50.00-50.00
(±0.01unit)
50-22
TOTAL_PITCH
_MAIN (F)_U
Sampling
reference pitch
all-color
average value
Main scan F
(Rising)
-50.00-50.00
(±0.01unit)
50-22
Item
classific
ation
Display Item content
Setting
range
Related
SIM
Sampling
status
check (1)
TOTAL_PITCH
_MAIN (F)_D
Sampling
reference pitch
all-color
average value
Main scan F
(Falling)
-50.00-50.00
(±0.01unit)
50-22
TOTAL_PITCH
_MAIN (R)_U
Sampling
reference pitch
all-color
average value
Main scan R
(Rising)
-50.00-50.00
(±0.01unit)
50-22
TOTAL_PITCH
_MAIN (R)_D
Sampling
reference pitch
all-color
average value
Main scan R
(Falling)
-50.00-50.00
(±0.01unit)
50-22
LINEAR_SUB
_F_U
Sampling
linearity Sub
scan F (Rising)
-100.00-
100.00
(±0.01unit)
50-22
Sampling
status
check (2)
LINEAR_SUB
_F_D
Sampling
linearity Sub
scan F (Falling)
-100.00-
100.00
(±0.01unit)
50-22
LINEAR_SUB
_R_U
Sampling
linearity Sub
scan R (Rising)
-100.00-
100.00
(±0.01unit)
50-22
LINEAR_SUB
_R_D
Sampling
linearity Sub
scan R
(Falling)
-100.00-
100.00
(±0.01unit)
50-22
LINEAR_MAIN
_F_U
Sampling
linearity Main
scan F (Rising)
-100.00-
100.00
(±0.01unit)
50-22
LINEAR_MAIN
_F_D
Sampling
linearity Main
scan F (Falling)
-100.00-
100.00
(±0.01unit)
50-22
LINEAR_MAIN
_R_U
Sampling
linearity Main
scan R (Rising)
-100.00-
100.00
(±0.01unit)
50-22
LINEAR_MAIN
_R_D
Sampling
linearity Main
scan R
(Falling)
-100.00-
100.00
(±0.01unit)
50-22
Sampling
status
check (3)
PITCH_SUB_F
_U
Sampling pitch
calculation
value Sub scan
F (Rising)
-50.00-50.00
(±0.01unit)
50-22
PITCH_SUB_F
_D
Sampling pitch
calculation
value Sub scan
F (Falling)
-50.00-50.00
(±0.01unit)
50-22
PITCH_SUB_R
_U
Sampling pitch
calculation
value Sub scan
R (Rising)
-50.00-50.00
(±0.01unit)
50-22
PITCH_SUB_R
_D
Sampling pitch
calculation
value Sub scan
R (Falling)
-50.00-50.00
(±0.01unit)
50-22
PITCH_MAIN_F
_U
Sampling pitch
calculation
value Main
scan F (Rising)
-50.00-50.00
(±0.01unit)
50-22
PITCH_MAIN_F
_D
Sampling pitch
calculation
value Main
scan F (Falling)
-50.00-50.00
(±0.01unit)
50-22
PITCH_MAIN_R
_U
Sampling pitch
calculation
value Main
scan R (Rising)
-50.00-50.00
(±0.01unit)
50-22
Item
classific
ation
Display Item content
Setting
range
Related
SIM
