Sharp MX-C310

COIN VEND INTERFACE
SHARP
18
All MX series machines have a coin vend interface located on the PCU Main PWB. The vending device
activates various signals to indicate paper sizes and operation.
Connector Manufacture: JST (www.jst.com)
Connector Type PND series
Connector Part Code (Wire Side) PNDP-16V-Z
Before connecting a third party auditor, the device should confirm to the following:-
1. The auditor interface should be optically isolated from the copier.
2. The device should be Power Supply Unit independent.
3. The device power supply unit should be a plug top adapter, not internal.
4. The plug top adapter should have a reinforced insulation barrier.
5. The audit device MUST comply and display the relevant safety approval mark (C-Tick, CE
or equivalent).
To enable coin vend function, test simulation 26 –03 should be set as required:-
Coin Vendor Mode
Diagnostic
Setting
The specified
quantity is
completed.
Remainder of money
is left
Insufficient money during copy job
The specified
quantity is
completed.
No money
remaining
Black/Colour
(No money
remaining)
Colour
(Remainder of
money left)
Condition 1
Condition 2
Condition 3
Condition 4
MODE 1
Operation 1
Operation 2
Operation 2
Operation 1
MODE 2
Operation 1
Operation 1
Operation 2
Operation 1
MODE 3
Operation 1
Operation 3
Operation 2
Operation 3
OPERATION 1 Wait for auto clear setting time
(Default 60sec – can be changed by the system setting)
OPERATION 2 Auto clear is not made.
OPERATION 3 Setting is immediately cleared.
Cont’d
