USB Device:
1. Insert the USB memory device containing the firmware file into the main USB Port.
2. Enter Simulation 49-01.
Note: “If no USB device is detected, an error message will be displayed.
3. Browse and select the correct firmware file by using the following methods:-
For MXC310/380 series only:
To browse the required folder containing the MXC310/380 firmware file, enter the
folder number and press the shortcut key on the operation panel.
Example shown:- Folder <DIR> MXC310_380_0102F0000 = 01.
Select the MXC310/380 firmware file by entering the file number and press the shortcut
key on the operation panel.
Example shown:- Filename 0102F000.sfu = 01.
To select individual areas only (eg ICU Main & ICU Boot), enter the relevant firmware
number and press the shortcut key . Each item selected will now be highlighted.
Example shown ICU Main (01) and ICU Boot (02).
