11
PG-C30XU
Connection Pin Assignments
Analog Computer 1 and 2 Signal Input Ports: 15-pin mini D-sub female connector
Computer Input
Component Input
Analog
1. Video input (red)
1. P
R
(C
R
)
2. Y
3. P
B
4. Not connected
5. Not connected
6. Earth (P
R
)
7. Earth (Y)
8. Earth (P
B
)
9. Not connected
10. Not connected
11. Not connected
12. Not connected
13. Not connected
14. Not connected
15. Not connected
2. Video input
(green/sync on green)
3. Video input (blue)
4. Reserve input 1
5. Composite sync
6. Earth (red)
7. Earth (green/sync on green)
8. Earth (blue)
9. Not connected
10. GND
11. GND
12. Bi-directional data
13. Horizontal sync signal
14. Vertical sync signal
15. Data clock
1
15
5
6
11
10
RS-232C Terminal: 9-pin Mini DIN connector
6
8
4
9
7
3
5
21
RS-232C Port: 9-pin D-sub male connector of the DIN-D-sub RS-232C cable
1
5
6
9
Pin No.
1
2
3
4
5
6
7
8
9
Pin No.
1
2
3
4
5
6
7
8
9
Signal
CD
RD
SD
ER
SG
DR
RS
CS
CI
Signal
VCC
RD
SD
EXIR
SG
ERX
RS
CS
ETX
I/O
Input
Output
Output
Output
Input
I/O
Output
Input
Output
Input
Input
Output
Input
Output
Name
Receive Data
Send Data
Signal Ground
Data Set Ready
Request to Send
Clear to Send
Name
+3.3V (Reserved)
Receive Data
Send Data
Detector of Option Unit
(Reserved)
Signal Ground
IR Receive Signal from
IR Amplifier (Reserved)
Request to Send
Clear to Send
IR Transmit Signal
(Reserved)
Reference
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
Connected to internal circuit
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
Reference
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
Connected to internal circuit
Not connected
Connected to internal circuit
Connected to internal circuit
Not connected
