Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
121
PG-C30XU
RUNTK0677CEZZ
INLET UNIT
PACKAGED CIRCUIT
å TNR761 9FJ0F20001280 J ENE471D10A AD
COILS
å L761 9FJ0L05001460 J ADR18-03-030Y
å L762 9FJ0L05001460 J ADR18-03-030Y
L763 9FJ0L08001660 J AFP10-60-080 AG
CAPACITORS
å C761 9FJ0C34001763 J 0.22 250V M.Polyester
å C762 9FJ0C51001223 J 1000p 250V Ceramic AD
å C763 9FJ0C51001223 J 1000p 250V Ceramic AD
å C764 9FJ0C34001753 J 0.1 250V M.Polyester
å C765 9FJ0C34001763 J 0.22 250V M.Polyester
å C766 9FJ0C34001763 J 0.22 250V M.Polyester
å C767 9FJ0C34001763 J 0.22 250V M.Polyester
RESISTOR
R761 9FJ0R11002110 J 470k 1/2W AC
MISCELLANEOUS PARTS
F761 9FJ0E02101020 J Fuse 5A 250V
9FJ0G10003930 J Connector, 3-pin (PF) S2P3-VH AD
RDENC0311CEZZ
POWER UNIT
INTEGRATED CIRCUITS
å IC701 9FJ0F01901370 J FA5332P
å IC702 9FJ0F09001050 J FA5315P
IC703 9FJ0F01102505 J HA17431VLPEL
TRANSISTORS
Q701 9FJ0Q02001725 J 2SC4409 AE
Q702 9FJ0Q11001592 J 2SK2837 AU
Q703 9FJ0D40010160 J TF561S
Q704 9FJ0Q11010692 J FS5KM16A
Q705 9FJ0Q00001065 J 2SA1162YT AC
DIODES
å D701 9FJ0D13000160 J Diode D5SB60 AK
D702 9FJ0D01010035 J Diode TVR5JTPA AC
D703 9FJ0D00001005 J Diode 1SS119T AB
D704 9FJ0D01010035 J Diode TVR5JTPA AC
D705 9FJ0D01010035 J Diode TVR5JTPA AC
D706 9FJ0D01001555 J Diode AK03V0
D707 9FJ0D04001000 J Diode D5L60
D708 9FJ0D01010035 J Diode TVR5JTPA AC
D709 9FJ0D01010035 J Diode TVR5JTPA AC
D710 9FJ0D01010035 J Diode TVR5JTPA AC
D711 9FJ0D24001230 J Diode SF10SC6
D712 9FJ0D03001113 J Diode S3L20U
D713 9FJ0D23010022 J Diode FMX12S AH
ZD701 9FJ0D31181695 J Zener Diode RD24JSAB2TA AC
ZD702 9FJ0D31181695 J Zener Diode RD24JSAB2TA AC
ZD703 9FJ0D31181695 J Zener Diode RD24JSAB2TA AC
ZD704 9FJ0D31181695 J Zener Diode RD24JSAB2TA AC
ZD705 9FJ0D31110125 J Zener Diode RD5.1JSAB2TA AD
PACKAGED CIRCUITS
å PC701 9FJ0F10010931 J Photo Coupler TLP721FD4GR AG
å PC702 9FJ0F10010931 J Photo Coupler TLP721FD4GR AG
å PC703 9FJ0F10010931 J Photo Coupler TLP721FD4GR AG
COILS AND TRANSFORMER
L701 9FJ0L08001850 J Inductor THNW23-06251
L702 9FJ0L08001025 J Inductor B-01-AT AC
L703 9FJ0L08001025 J Inductor B-01-AT AC
L704 9FJ0L08001025 J Inductor B-01-AT AC
å T701 9FJ0L00501170 J Transformer 050117
CONTROL
VR701 9FJ0R60001255 J 1k 1/10W AE
CAPACITORS
C701 9FJ0C32410040 J 2.2 400V M.Polyester AN
C702 9FJ0C50004335 J 0.22 25V Ceramic (Chip)
C703 9FJ0C01401985 J 100 35V Electrolytic AE
C704 9FJ0C01502455 J 22 50V Electrolytic AC
C705 9FJ0C50003455 J 470p 1kV Ceramic AK
C706 9FJ0C02801643 J 150 420V Electrolytic
C707 9FJ0C50002015 J 0.01 50V Ceramic AB
C708 9FJ0C50004365 J 0.15 25V Ceramic (Chip)
C709 9FJ0C50004375 J 68p 50V Ceramic (Chip)
C710 9FJ0C50011465 J 470p 50V Ceramic (Chip)
C711 9FJ0C50002635 J 0.047 50V Ceramic AC
C712 9FJ0C50011465 J 470p 50V Ceramic (Chip)
C713 9FJ0C50002015 J 0.01 50V Ceramic AB
C714 9FJ0C50004365 J 0.15 25V Ceramic (Chip)
å C716 9FJ0C51001223 J 1000p 4kV Ceramic AD
C717 9FJ0C50002015 J 0.01 50V Ceramic AB
C718 9FJ0C21201035 J 4700p 200V Ceramic
C719 9FJ0C50010715 J 220p 1kV Ceramic AD
C720 9FJ0C50004325 J 0.22 16V Ceramic (Chip)
C721 9FJ0C50011465 J 470p 50V Ceramic (Chip)
C722 9FJ0C50002635 J 0.047 50V Ceramic AC
C723 9FJ0C50002635 J 0.047 50V Ceramic AC
C724 9FJ0C01401635 J 47 35V Electrolytic AD
C725 9FJ0C50002985 J 1000p 500V Ceramic AD
C726 9FJ0C01102040 J 1000 10V Electrolytic
C727 9FJ0C01102040 J 1000 10V Electrolytic
C728 9FJ0C50003745 J 0.1 50V Ceramic (Chip)
C729 9FJ0C50002985 J 1000p 500V Ceramic AD
C730 9FJ0C01302155 J 220 25V Electrolytic
C731 9FJ0C01302140 J 470 25V Electrolytic
å C732 9FJ0C51001223 J 1000p 4kV Ceramic AD
C733 9FJ0C50004335 J 0.22 25V Ceramic (Chip)
C734 9FJ0C01510195 J 3.3 50V Electrolytic
RESISTORS
R701 9FJ0R94201715 J 9.1k 1/2W Chip
R702 9FJ0R94201715 J 9.1k 1/2W Chip
R703 9FJ0R91201445 J 47k 1/10W Chip AB
R704 9FJ0R94201005 J 10 1/2W Chip AC
R705 9FJ0R17070491 J 10 2W Metal Oxide AC
R706 9FJ0R70010070 J 10 5W Cement AH
R707 9FJ0R22110330 J 0.1 5W Cement
R708 9FJ0R94201305 J 3.3k 1/2W Chip
R709 9FJ0R91201245 J 1k 1/10W Chip AB
R710 9FJ0R91501065 J 470k 1/10W Chip
R711 9FJ0R91501065 J 470k 1/10W Chip
R712 9FJ0R91501065 J 470k 1/10W Chip
R713 9FJ0R91501025 J 8.2k 1/10W Chip
R714 9FJ0R91501065 J 470k 1/10W Chip
R715 9FJ0R91501065 J 470k 1/10W Chip
R716 9FJ0R91501065 J 470k 1/10W Chip
R718 9FJ0R91501005 J 5.6k 1/10W Chip
R719 9FJ0R91501065 J 470k 1/10W Chip
R720 9FJ0R91501065 J 470k 1/10W Chip
R721 9FJ0R91501065 J 470k 1/10W Chip
R722 9FJ0R91501005 J 5.6k 1/10W Chip
R723 9FJ0R91201505 J 150k 1/10W Chip
R724 9FJ0R91201425 J 33k 1/10W Chip
R725 9FJ0R91201455 J 56k 1/10W Chip
R726 9FJ0R91201365 J 10k 1/10W Chip AB
R727 9FJ0R91201055 J 27 1/10W Chip
R728 9FJ0R91201405 J 22k 1/10W Chip
R729 9FJ0R91201485 J 100k 1/10W Chip
R730 9FJ0R92201115 J 82 1/8W Chip
