16
PG-C30XU
4. Removing the optical mechanism unit
4-1. Remove the six optical mechanism unit lock screws. Lift the unit off the position.
4-2. Remove the two lamp socket holder lock screws and take out the holder.
4-1
Optical Mechanism Unit
Duct Fan Unit
4-2
