PN-K321/K322B HARDWARE DESCRIPTIONS 8 - 8
CN No. Pin No. Pin Name Function
CN901
LVDS output
Connecter 1
1 GND GND
2 LVTX_D_CH4P LVDS data
3 LVTX_D_CH4N LVDS data
4 LVTX_D_CH3P LVDS data
5 LVTX_D_CH3N LVDS data
6 LVTX_D_CLKP LVDS clock
7 LVTX_D_CLKN VLDS clock
8 LVTX_D_CH2P LVDS data
9 LVTX_D_CH2N LVDS data
10 LVTX_D_CH1P LVDS data
11 LVTX_D_CH1N LVDS data
12 LVTX_D_CH0P LVDS data
13 LVTX_D_CH0N LVDS data
14 LVTX_C_CH4P LVDS data
15 LVTX_C_CH4N LVDS data
16 LVTX_C_CH3P LVDS data
17 LVTX_C_CH3N LVDS data
18 LVTX_C_CLKP LVDS clock
19 LVTX_C_CLKN VLDS clock
20 LVTX_C_CH2P LVDS data
21 LVTX_C_CH2N LVDS data
22 LVTX_C_CH1P LVDS data
23 LVTX_C_CH1N LVDS data
24 LVTX_C_CH0P LVDS data
25 LVTX_C_CH0N LVDS data
26 GND GND
27 LVTX_B_CH4P LVDS data
28 LVTX_B_CH4N LVDS data
29 LVTX_B_CH3P LVDS data
30 LVTX_B_CH3N LVDS data
31 LVTX_B_CLKP LVDS clock
32 LVTX_B_CLKN VLDS clock
33 LVTX_B_CH2P LVDS data
34 LVTX_B_CH2N LVDS data
35 LVTX_B_CH1P LVDS data
36 LVTX_B_CH1N LVDS data
37 LVTX_B_CH0P LVDS data
38 LVTX_B_CH0N LVDS data
39 LVTX_A_CH4P LVDS data
40 LVTX_A_CH4N LVDS data
41 LVTX_A_CH3P LVDS data
42 LVTX_A_CH3N LVDS data
43 LVTX_A_CLKP LVDS clock
CN No. Pin No. Pin Name Function
CN901
LVDS output
Connecter 1
44 LVTX_A_CLKN VLDS clock
45 LVTX_A_CH2P LVDS data
46 LVTX_A_CH2N LVDS data
47 LVTX_A_CH1P LVDS data
48 LVTX_A_CH1N LVDS data
49 LVTX_A_CH0P LVDS data
50 LVTX_A_CH0N LVDS data
51 GND GND
CN2202
LVDS output
Connecter 2
1 GND GND
2 LVTX_D_CH4P LVDS data
3 LVTX_D_CH4N LVDS data
4 LVTX_D_CH3P LVDS data
5 LVTX_D_CH3N LVDS data
6 LVTX_D_CLKP LVDS clock
7 LVTX_D_CLKN VLDS clock
8 LVTX_D_CH2P LVDS data
9 LVTX_D_CH2N LVDS data
10 LVTX_D_CH1P LVDS data
11 LVTX_D_CH1N LVDS data
12 LVTX_D_CH0P LVDS data
13 LVTX_D_CH0N LVDS data
14 LVTX_C_CH4P LVDS data
15 LVTX_C_CH4N LVDS data
16 LVTX_C_CH3P LVDS data
17 LVTX_C_CH3N LVDS data
18 LVTX_C_CLKP LVDS clock
19 LVTX_C_CLKN VLDS clock
20 LVTX_C_CH2P LVDS data
21 LVTX_C_CH2N LVDS data
22 LVTX_C_CH1P LVDS data
23 LVTX_C_CH1N LVDS data
24 LVTX_C_CH0P LVDS data
25 LVTX_C_CH0N LVDS data
26 GND GND
27 LVTX_B_CH4P LVDS data
28 LVTX_B_CH4N LVDS data
29 LVTX_B_CH3P LVDS data
30 LVTX_B_CH3N LVDS data
31 LVTX_B_CLKP LVDS clock
32 LVTX_B_CLKN VLDS clock
