Sharp PN-K321 Service Manual

PN-K321/K322B INSTALLATION, ADJUSTMENT, SETTING 2 - 11
ITEM DETAIL 1 DETAIL 2 ALTANATIVE ADJUSTMENT DEFAULT VALUE
PC
AV AV
PC PC
AV
PC
DisplayPort
HDMI1 HDMI2 HDMI1 HDMI2
HDMI DUAL HDMI DUAL
SETUP LANGUAGE
JAPANISE
For JAPAN→
JAPANISE
For overseas
shipment→
ENGLISH
● ● ● ● ● ● ●
ENGLISH ● ● ● ● ● ● ●
DEUTSCH ● ● ● ● ● ● ●
FRANÇAIS ● ● ● ● ● ● ●
ITALIANO ● ● ● ● ● ● ●
ESPAÑOL ● ● ● ● ● ● ●
РУССКИЙ ● ● ● ● ● ● ●
INPUTSELECT HDMI1 AV
PC HDMI
● ● ● ● ● ● ●
PC ● ● ● ● ● ● ●
HDMI2 AV
PC HDMI
● ● ● ● ● ● ●
PC ● ● ● ● ● ● ●
HDMI DUAL OFF
OFF
○ ○ ○ ○ ○ ○ ○
ON ○ ○ ○ ○ ○ ○ ○
AUDIO SELECT DisplayPort
DisplayPort
● ● ● ● ● ● ●
STEREO MINI ● ● ● ● ● ● ●
HDMI ● ● ● ● ● ● ●
AUDIO INPUT LEVEL Value 1.0, 0.5 0.5 ● ● ● ● ● ● ●
TOUCH OUTPUT SETTING
*K322B only
ALWAIS/
DisplayPort/HD
MI1/HDMI2/HD
MI DUAL
ALWAIS
● ● ● ● ● ● ●
COMMUNICATION SETTING
Value
9600, 19200,
38400
38400
● ● ● ● ● ● ●
DisplayPort Stream DisplayPort Stream SST SST ● ● ● ● ● ● ●
MST ● ● ● ● ● ● ●
MONITOR
MONITOR LANDSCAPE LANDSCAPE
● ● ● ● ● ● ●
PORTRAIT ● ● ● ● ● ● ●
STANDBY MODE
STANDARD STANDARD
● ● ● ● ● ● ●
LOW POWER
● ● ● ● ● ● ●
OFF IF NO OPERATION
OFF OFF
● ● ● ● ● ● ●
ON ● ● ● ● ● ● ●
TOUCH MODE AT STARTUP
*K322B only
RESET/NO
RESET
RESET
● ● ● ● ● ● ●
MARK DISPLAY
*K322B only
TOUCH
MARK DISPLAY
5S/ALWAYS 5S
● ● ● ● ● ● ●
CHANGE
DISPLAY POSITION
RIGHT/BOTTO
M/LEFT/TOP
RIGHT
● ● ● ● ● ● ●
