PN-K321/K322B OUTLINE OF THE PRODUCT 1 - 4
1 – 3.Compatible signal timing (PC)
Screen resolution Vsync
VESA
640×480
60Hz
72Hz
75Hz
800×600
56Hz
60Hz
72Hz
75Hz
848×480 60Hz
1024×768
60Hz
70Hz
75Hz
1152×864 75Hz
1280×768
60Hz
75Hz
1280×800 60Hz
1280×960 60Hz
1280×1024
60Hz
75Hz
1360×768 60Hz
1400×1050 60Hz
*1 A single screen is created from simultaneous input of two systems using HDMI1 and HDMI2.
*2 Displays a reduced image, except in Dot by Dot. In Dot by Dot, the image will be cut down to panel size then displayed.
*3 Displays using multi-streaming.
*4 The two HDMI input terminals both have 1920 x 2160 signals.
*5 The two HDMI input terminals both have 2048 x 2160 signals.
*6 The signals for the left and right screens are both 1920 x 2160 signals.
* All are compliant only with non-interlaced.
* Depending on the connected PC, images may not be displayed properly even if the compatible signal described above is input.
