Sharp SX 1075

ITEM CONTROL # DESCRIPTION PART NUMBER VENDOR QTY
146 706810-01 Spring, Ext, .180" X .024" X 1.25" 17-2748-04 Datamax 1
147 706811-01 Slip Clutch Assembly 17-2470-01 Datamax 1
148 706342-01
Sleeve Bushing, .377" X .592" X 1/4"
17-2753-01 Datamax 6
149 706813-01 Drive Motor Assembly, 203 DPI 24-2521-01 Datamax 1
150 706814-01 Printhead Assembly 15-2915-01 Datamax 1
151 706815-01 Spring Wave Washer 17-2317-08 Datamax 1
152 706785-01 Thermal Printhead, 203 Dpi, 6" 20-2164-01 Datamax 1
153 706816-01 Metric S.H.C.S. M3x0.5 X 10 10-2512-03 Datamax 2
154 706817-01 Center Plate 12-2734-01 Datamax 1
SECTION 5- PARTS LIST
SX™
Service and Maintenance Manual 5-8 960714-
02B © 2007 92407
PRINTHEAD CRADLE ASSEMBLY (MODEL 1108)
