Service and Maintenance Manual 1-1 960714-02B © 2007 I2407
ABOUT THIS MANUAL
This manual has been prepared for your use in
servicing the Sharp SX™ Packaging Machine and
the Sharp SX™ Packaging Machine with Printer.
Included in the procedures are helpful facts on
service, troubleshooting, specifications and parts
information.
All procedures should be performed by a qualified
service technician.
It is important that you familiarize yourself with the
product as much as possible before initiating any
maintenance, troubleshooting or repairs.
Make sure you read through the IMPORTANT
SAFETY INFORMATION and INTRODUCTION
sections of this manual before attempting any
service procedures.
As you disassemble your machine to service and
replace parts, keep the following points in mind:
• Do not remove or loosen more parts than
needed. Use common sense to keep your work
to a minimum.
• Mark any wires before disconnecting to make
reassembly easier.
• Use Loctite® Blue or equivalent on all threaded
fasteners without lock washers.
Within the Component Repair section of this
manual, each repair procedure is broken down into
three main categories for each component. These
categories are Testing, Adjustment, and
Replacement and are identified by the following
symbols:
Accompanying this manual, attached to the inside
front cover, is a Compact Disc containing an
electronic color version of this manual in Acrobat .pdf
format along with other useful digital content. For
more information view the README.TXT file located
on the CD.
Adobe Reader is required to view .pdf files and can
be downloaded free of charge from the following
website:
http://www.adobe.com/products/acrobat/alternate.html#50
The digital color version of the manual is also
interactive, allowing the user to simply click onto a
subject within the Table of Contents to take them to
the specified page.
This manual is designed to be used by Authorized Service Personnel only. Sharp
Packaging Systems, Inc. assumes no responsibility for any repairs made on Sharp
Packaging units by anyone other than Authorized Service Technicians.
