Connections
11
1. Installation
Attach the paper tray and paper tray extension
Attach the paper tray and paper tray extension.
Note: The paper tray extension has a top side
and a bottom side. If you cannot insert the
tabs into the holes, turn the support over.
Insert
horizontally
and rotate up
Extension phone (optional)
If desired, you can connect an extension phone to the TEL. SET socket on the
fax.
♦ To connect an answering machine to your fax, see page 49.
1 Remove the seal covering the TEL. SET
socket.
2 Connect the extension phone line to
the TEL. SET socket using the
provided adapter.
• Eire: Insert the extension phone line
directly into the TEL. SET socket.
TEL.SET
TEL.LINE
all.bookPage11Monday,August19,20024:05PM
