Sharp UX-P115 User Manual

UX-P115U
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] Cabinet,etc.
3 CCNWN395BXH01 AP C Speaker ass'y
4 CLEVP2358XH01 AD C Hook switch lever ass'y
5 CROLR2481XH01 AQ C PO roller ass'y
6 DCEKC688TXHZZ BT N E Control PWB unit(Within ROM)
7 DCEKL477CXH02 BG E TEL/LIU PWB unit
8 QPWBF3368XHZ2 AQ E Wire holder(PWB only)
16 QCNWN399BXHZZ AP C Panel cable
17 LBNDJ2006XHZZ AA C Band(100mm)
22 LBSHP2140XHZA AC C Back bearing,left
23 LBSHP2143XHZZ AC C Back bearing,right
24 LFRM-2225XHVA AP C Scanner frame
25 MSPRC3295XHZZ AB C CIS spring
26 MSPRD3379XHZZ AD C PO pinch roller spring
27 NGERH2569XHZZ AC C Back gear
28 NGERH2570XHZZ AD C Reduction gear,21/37Z
29 NROLP2332XHZZ AD C PO pinch roller
30 NROLR2482XHZZ AR C Back roller
31 PGIDM2617XHZZ AD C CIS guide,left
32 PGIDM2618XHZZ AD C CIS guide,right
33 QCNWN419BXHZZ AL C CIS cable
34 RUNTZ2127XHZZ N B CIS unit
35 GCABB2393XHSH AZ D Lower cabinet
36 LHLDZ2227XHZZ AD C Ink ribbon spool 1
37 LHLDZ2228XHZZ AD C Ink ribbon spool 2
38 MSPRC3287XHZZ AB C Head spring A
39 MSPRC3288XHZZ AB C Head spring B
40 MSPRC3340XHZA AD C Head spring C
41 PCOVP2130XHZZ AE C Head cover
42 PGIDM2615XHZZ AD C Head guide,left
43 PGIDM2616XHZZ AD C Head guide,right
44 QCNWN486AXHZZ AM C Head cable
45 RHEDZ2065XHZZ BP B Thermal head
46 GCOVA2447XHVA AL D Front cover
47 GLEGG2078XHZZ AD C Rubber leg
48 LPLTM3178XHZZ AF C Bottom plate
49 LPLTP3177XHZZ AD C Stopper plate
50 MLEVP2357XHZZ AD C Film sensor lever
51 MLEVP2356XHZA AD C P-IN sensor lever,lower
52 MSPRD3286XHZA AB C Film sensor lever spring
53 MSPRD3285XHZZ AB C P-IN sensor lever spring,lower
54 MSPRD3291XHZZ AD C Speaker hold spring
55 MSPRD3292XHZA AB C Head earth spring
57 PCOVP2131XHVA AG C Panel cable cover
58 PCOVP2132XHZZ AD C Control PWB cover
!
59 QACCD2090XHZZ AS N B AC cord ass'y
!
61 RDENT2198XHZZ BG E Power supply PWB unit
62 HPNLH2420XHSN AM N D Decoration panel
63 PBRS-2055XHZZ AN C Static brush
64 PSHEZ3687XHZZ AD C Earth sheet
65 MSPRD3341XHZZ AD C Up spring
66 MSPRC3346XHZZ AD C Head spring D
67 MSPRC3357XHZZ AD C PO roller spring
68 TLABH498FXHZZ AH D Imaging film set label
B1 XEBSD30P10000 AA C Screw(3x10)
B2 XEBSD30P12000 AA C Screw(3x12)
B3 LX-BZ2282XHZZ AB C Screw(4x6)
B4 XEPSD30P08000 AA C Screw(3x8)
W1 XWHSN40-08100 AA C Washer
W2 LX-WZ2290XHZZ AE C Washer
